ALSTOM UT150‑1 Communication Control Module

Technical Specifications

Model：UT150‑1

Brand：ALSTOM

Product Type：Communication control module

Applicable System：ALSTOM CE2000 F8000 control rack,power plant process control system

Supply Voltage：24V DC (18‑30VDC range),backplane power supply

Typical Current：150mA

Communication Interface：WorldFIP fieldbus,1Mbps copper medium

I/O Expansion Capacity：Supports up to 16 peripheral I/O modules

Processor：DSP digital signal processing chip

Status Indicator：Multi‑color LED for power,bus activity,communication fault and module status

Built‑in Function：Fieldbus data exchange,I/O module management,signal data processing,over‑voltage / under‑voltage / over‑current protection,self‑diagnosis

Working Temperature：‑20℃ ~ +60℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Plug‑in slot installation inside control rack

Dimension：150mm100mm50mm

Weight：0.40kg

Product Brief:

UT150‑1 is legacy plug‑in communication control module for ALSTOM CE2000 F8000 rack system. It serves as fieldbus master unit based on WorldFIP 1Mbps protocol,responsible for data interaction between rack main controller and peripheral I/O modules. It supports up to 16 I/O modules expansion,executes data transmission,signal processing and hardware protection functions. Front‑panel LED indicators support quick on‑site bus and module fault diagnosis without extra testing tools. Plug‑in cabinet mounting structure enables convenient disassembly and replacement. This is EOL discontinued spare part,widely used for thermal power plant old‑generation control system maintenance and renovation. Please confirm hardware revision and F8000 rack compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
