Anton Paar Multiwave 7101 Microwave Digestion Instrument Unit

Module Feature

Multiwave 7101 is Anton Paar laboratory-grade microwave sample digestion instrument, belongs to Multiwave 7000 series. It adopts PDC pre-pressurized digestion cavity technology, maximum microwave output power 1500W, supports high temperature and high pressure closed acid digestion. The equipment has multi-level redundant safety protection mechanism, corrosion-resistant cavity structure, suitable for aqua regia, hydrochloric acid, hydrofluoric acid and other strong corrosive digestion reagents. Built-in workflow guided program, supports one-batch multi-sample simultaneous digestion, matching TFM / quartz digestion vessels of different specifications. Widely used in environmental monitoring, geological mineral, food safety, pharmaceutical and petrochemical laboratories, as sample pretreatment equipment before elemental content testing such as ICP, ICP-MS and atomic absorption.

Working principle

Microwave energy directly acts on the polar molecules inside the digestion reagent, rapid heating and pressure rise inside the sealed digestion tank. Under high temperature and high pressure, the organic and inorganic matrix of the sample is rapidly decomposed and dissolved into the acid solution. The built-in temperature and pressure sensors monitor the state of each rotor tank in real time, and the host adjusts the microwave output power dynamically according to the set temperature curve, to realize controllable closed digestion. After digestion is completed, the built-in cooling system reduces the temperature and pressure safely before opening the cavity.

Onboard components

Microwave magnetron power assembly, PDC pressurized digestion cavity, corrosion-resistant rotor bracket, temperature & pressure optical fiber sensor, touch screen industrial controller, built-in cooling air circuit, safety interlock door lock assembly, exhaust gas adsorption channel, communication circuit board, compatible TFM / quartz digestion vessels.

LED indicators

Front touch screen with digital status display; LED status lights for power, running, alarm and fault. Real-time display of cavity temperature, pressure, program progress and fault alarm information.

Hardware self‑diagnosis

Self-diagnosis covers microwave power anomaly, fiber temperature sensor failure, cavity over-temperature, over-pressure, door interlock fault, cooling fan failure, exhaust abnormality. Fault codes and running logs are stored in the instrument memory, which can be exported together with digestion method files.

Programming software

Local touch screen can edit digestion temperature-time curve methods; supporting Anton Paar LabWare upper computer software for method management, data record export, audit trail and LIMS system docking.

Electrical & Process Parameters

Model:Multiwave 7101 Brand:Anton Paar Device type:Laboratory Microwave Digestion System Microwave power:1500 W Max working temperature:300 ℃ Max working pressure:Up to 30 bar Cavity type:PDC pre-pressurized digestion cavity Reagent compatibility:Aqua regia, HCl, HNO3, HF and other strong corrosive acids Communication:Ethernet Function:Closed high-temperature high-pressure acid digestion for laboratory elemental analysis sample pretreatment

Mechanical & Structure

Mounting:Laboratory bench placement Protection class:Lab safety protection enclosure Housing:Anti-corrosion coated metal cabinet

Environmental

Operating temperature:10℃ ~ +35℃ Storage temperature:-10℃ ~ +60℃ Ambient humidity:20~80% non‑condensing Certification:CE compliant, laboratory analytical instrument standard Status:Anton Paar original Multiwave series microwave digestion system

Installation

Place the instrument on a stable laboratory bench with independent exhaust ventilation. Connect power supply and exhaust pipeline, match external circulating cooler if needed. Install the selected rotor and digestion tank, set digestion temperature and pressure program on the touch screen, then perform blank test and standard sample verification before formal sample testing. Comply with laboratory microwave digestion safety operation specification.

Interface

Ethernet communication port, exhaust gas interface, cooling water interface (optional), power terminal.

Diagnostic

Digestion temperature cannot rise:Magnetron aging, microwave power attenuation or cavity door seal leakage. Pressure over-limit alarm:Sample organic content is too high, digestion program heating ramp is too fast. Sensor reading abnormal:Fiber optic temperature sensor damage or optical path pollution. Cannot start program:Cavity door interlock not closed properly.

Product Brief

Anton Paar Multiwave 7101 microwave digestion system, 1500W power, PDC pre-pressurized cavity, high temperature and high pressure closed acid digestion, used for laboratory sample pretreatment before ICP / ICP-MS elemental analysis of environment, geology, food and pharmaceutical samples.
