APC 34000024SE UPS Control Board Unit

Feature & Principle

This circuit board collects voltage, current and temperature signals of the battery pack and power module. It implements battery charging management, fault judgment and alarm output, communicates with the main control board to feed back real-time running status of the UPS system.

Specifications

Model: 34000024SE Brand: APC (Schneider) Type: UPS monitoring PCBA Power supply: 24VDC Mounting: Installed inside UPS cabinet Protection: IP20 Certification: CE, UL

Components & Diagnostics

Signal sampling chip, charging management circuit, communication interface, terminal block and status indicator LEDs. Common faults include sampling value drift, battery detection failure, communication interruption and component burnout.

Product Brief

34000024SE circuit board assembly, APC power spare widely used for industrial UPS maintenance and replacement.
