Atlas Copco PF3102-C-HW Tightening Controller

Technical SpecificationsModel:PF3102-C-HW Brand:Atlas Copco Product Type:Power Focus3100 Basic Tightening Controller Power Supply:90-120/180-240V AC,50/60Hz,150W Mounting:Cabinet rack mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:9.2kg Dimension:410mm310mm165mm

System compatibilityPF3102-C-HW belongs to Atlas Copco Power Focus3100 series compact single-tool tightening controller. Compatible with Tensor series electric nutrunner tools. It is basic C version without integrated fieldbus; fieldbus communication can be realized by installing optional communication module. It can connect with PLC and MES after adding bus card for fastening result upload and production traceability.

FunctionPF3102-C-HW is compact torque-angle control base unit for automated bolt assembly. It supports multi-step tightening sequences, real-time torque-angle curve monitoring and OK/NOK fastening judgement. It stores fastening history records and supports parameter backup, built-in emergency stop safety relay. Profibus DP, DeviceNet or Interbus communication can be realized via optional communication module, widely used for small automotive component assembly stations.

InstallationCut off power before installation. Mount controller inside electrical cabinet. Connect AC power, tool motor cable and signal wiring. Install optional fieldbus module if required. Configure tightening programs via ToolsTalk software. Complete tool calibration and test tightening before online operation.

InterfaceSingle tool drive port, 24V digital I/O terminals, expansion slot for optional fieldbus module, basic display and operation keys, status LED indicators, E-stop safety relay terminal.

FeatureAtlas Copco Power Focus3100 compact torque controller, modular fieldbus expansion design, real-time torque-angle monitoring, built-in E-stop safety relay, fastening data storage, IP20 cabinet protection. Discontinued legacy spare part, used for single station bolt tightening system maintenance and replacement.

DiagnosticController no power: check AC input, fuse and wiring. Tool no rotation: inspect tool cable, motor winding and tool enable signal. Tightening result deviation: verify tool calibration, tightening program and joint mechanical condition. Fieldbus communication abnormal: check installed bus module, bus cable, node address and PLC configuration.

Product BriefAtlas Copco PF3102-C-HW is Power Focus3100 basic compact torque tightening controller, widely used in automotive and machinery assembly production lines for single station bolt fastening control, supports optional fieldbus module for factory network communication.
