Atlas CopcoAtlas Copco PF4000-G-HW Tightening Controller

Technical SpecificationsModel:PF4000-G-HW Brand:Atlas Copco Product Type:Power Focus 4000 Graph Version Tightening Controller Power Supply:100-120/200-240V AC,50/60Hz,320W Mounting:Cabinet rack mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:13kg Dimension:415mm319mm173mm

System compatibilityPF4000-G-HW belongs to Atlas Copco Power Focus 4000 series Graph model tightening controller. Compatible with Atlas Copco Tensor series electric nutrunner tools. The Graph version supports local standalone programming, can connect with PLC and MES system via optional fieldbus modules for fastening result upload and production traceability.

FunctionPF4000-G-HW is high precision torque-angle control unit for automated bolt assembly. It supports multi-step tightening strategies, real-time torque-angle curve monitoring and OK/NOK fastening judgement. The Graph hardware has complete local programming capability, can work independently as programming terminal for other Power Focus controllers. It stores fastening records, supports RBU rapid backup unit for parameter backup, built-in emergency stop safety relay, widely used in automotive and heavy machinery assembly lines.

InstallationCut off power before installation. Mount controller inside electrical cabinet. Connect AC power, tool motor cable and signal wiring. Configure tightening programs via local Graph interface or ToolsTalk software. Complete tool calibration and test tightening before online operation.

InterfaceTool drive port, 24V digital I/O terminals, local Graph HMI operation panel, status LED indicators, E-stop safety relay terminal, optional fieldbus expansion slot.

FeatureAtlas Copco PF4000 Graph version torque controller, local standalone programming function, torque-angle real-time monitoring, built-in E-stop safety relay, RBU parameter backup, fastening data traceability, IP20 cabinet protection. Obsolete legacy spare part, used for assembly line bolt tightening system maintenance and replacement.

DiagnosticController no power: check AC input, fuse and wiring. Tool no rotation: inspect tool cable, motor winding and tool enable signal. Tightening result deviation: verify tool calibration, tightening program and joint mechanical condition. HMI display fault: check internal display connector and controller firmware.

Product BriefAtlas Copco PF4000-G-HW is Power Focus 4000 Graph torque tightening controller, widely used in automotive and machinery assembly production lines for bolt fastening control and on-site program editing.

Disclaimer:All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
