B37170016000 Berger Lahr Servo Motor Unit

Module Feature

B37170016000 is a Berger Lahr high precision industrial servo motor. It adopts permanent magnet synchronous motor structure, featuring high torque density, low inertia and fast dynamic response. Built-in high-resolution encoder provides real-time position and speed feedback for closed-loop motion control. The motor winding is designed with thermal protection function, and reinforced bearing assembly ensures long service life under continuous cyclic operation. Equipped with standard power and encoder connectors, it can be matched with corresponding Berger Lahr servo drive system. Widely used in automated production equipment, linear positioning platforms, cutting machines and other precision motion control scenarios.

Working principle

The Berger Lahr servo driver outputs three-phase alternating current to the motor stator winding, generating rotating magnetic field to drive the permanent magnet rotor to rotate. The built-in encoder feeds back rotor position and speed signal to the servo controller in real time. The controller adjusts output current and frequency dynamically to maintain precise speed and position, realizing closed-loop positioning control.

Onboard components

Permanent magnet rotor, stator winding, high-resolution rotary encoder, thermal sensor, front and rear bearings, power connector, encoder signal connector, motor housing.

LED indicators

Encoder power LED, signal status LED.

Hardware self-diagnosis

Winding over-temperature, encoder signal loss, wiring open circuit, overcurrent detection, records fault alarm information.

Programming software

Berger Lahr PC software for motor parameter tuning, motion monitoring and encoder calibration.

Electrical & Process Parameters

Model:B37170016000 Brand:Berger Lahr Device type:Permanent Magnet Synchronous Servo Motor Control mode:Closed loop position / speed / torque control Feedback:Built-in high resolution encoder Protection:Over temperature, overcurrent, encoder fault, open circuit

Mechanical & Structure

Mounting:Flange mount Protection class:IP65 Housing:Aluminum alloy housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE compliant Status: Berger Lahr original high precision servo motor for industrial automation motion control

Installation

Follow ESD protection procedure before handling. Fix motor firmly on equipment flange, align coupling accurately to avoid radial and axial offset. Connect power cable and encoder cable to corresponding terminals, complete motor parameter auto-tuning before commissioning.

Interface

Motor power connector, encoder signal connector, thermal sensor terminal.

Diagnostic

Motor no rotation: power wiring error or encoder signal interruption. Vibration and abnormal noise: misalignment of coupling or bearing damage. Over-temperature alarm: excessive load or poor heat dissipation.

Product Brief

B37170016000 Berger Lahr high precision permanent magnet synchronous servo motor, built-in encoder, IP65 flange mount, for automated machinery precision positioning and motion control.
