Banner 15ERM Photoelectric Emitter Unit

Module Feature

15ERM belongs to Banner Mini-Beam series opposed photoelectric sensor. It is the emitter unit and must work together with corresponding receiver. Compact plastic housing, infrared light source, built-in reverse polarity protection. Widely used for material presence detection, part counting and conveyor object sensing.

Working principle

The emitter continuously transmits infrared light beam toward receiver. When workpiece breaks the light beam, the receiver outputs switching signal to PLC for logic judgment.

Onboard components

Infrared LED, drive PCB circuit, plastic housing, mounting holes, 4-pin M12 connector.

LED indicators

Power status LED.

Hardware self-diagnosis

Power supply check, LED health monitoring, wiring continuity inspection.

Programming software

No dedicated programming software.

Electrical & Process Parameters

Model:15ERM Brand:Banner Device type:Mini-Beam Through Beam Photoelectric Emitter Supply voltage:10-30VDC Light source:Infrared LED Connection:M12 connector Cooling:Natural convection cooling Protection:Reverse polarity protection

Mechanical & Structure

Mounting:Slot mounting Protection class:IP67 Housing:Plastic housing

Environmental

Operating temperature:-20℃ ~ +55℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE,cRUus compliant Status: Banner original Mini-Beam opposed beam emitter for factory automation sensing

Installation

Follow strict safety procedure before handling. Install emitter and receiver on two opposite sides, align optical axis. Connect power cable to M12 connector, test beam blocking function before commissioning.

Interface

M12 quick-disconnect connector, mounting slot holes.

Diagnostic

No beam output: power missing or LED burnout. Unstable signal: optical axis misalignment or dust on lens.

Product Brief

Banner 15ERM Mini-Beam through beam photoelectric emitter,10-30VDC IP67, used with matched receiver for object detection on conveyors and automation equipment.
