Basler PRS200 Synchronizing Check Relay

Feature & Principle

It continuously samples AC voltage signals from incoming generator and bus. Internal circuit compares phase angle, voltage deviation and frequency difference. When all parameters are within adjustable setting range, the relay contact closes to allow breaker closing. It blocks closing command if out of sync, avoids huge inrush current and winding damage. It supports single-phase and three-phase system configuration.

Specifications

Model: PRS200 Brand: Basler Electric Signal input: 120~480V AC Frequency: 50/60Hz Output: Relay contact Adjustable phase window: 5~30° Adjustable voltage difference: 5~20% Power supply: 120/240V AC Mounting: Panel mount Certification: UL, CE

Components & Diagnostics

Signal sampling circuit, phase detection chip, relay output unit, status indicator lamp, adjustment potentiometer. Common faults: no sync output, false closing permission, signal loss alarm, contact burnout, parameter drift.

Product Brief

PRS200 synchronizing relay, Basler power control spare widely used for industrial generator cabinet, marine power station and power distribution paralleling panel maintenance.
