Leuze MLC500T14-750 Safety Light Curtain Transmitter

Feature & Principle

It emits synchronized infrared beams to match the corresponding receiver. When any beam is blocked, the safety signal is cut off to trigger machine stop. It meets Type4, PL e / SIL3 safety standard, optical synchronization design, supports flexible mounting for mechanical safety guarding.

Specifications

Model: MLC500T14-750 Brand: Leuze Series: MLC500 Type: Transmitter Resolution: 14 mm Protective field height: 750 mm Operating range: 0~6 m Safety level: Type4, PL e, SIL3 Power supply: 24VDC Housing: Metal casing Certification: CE

Components & Diagnostics

Infrared light emitting unit, main circuit board, status LED indicator, cable connector. Common faults: beam signal loss, communication failure, indicator alarm, short circuit damage, mounting misalignment.

Product Brief

MLC500T14-750 light curtain transmitter, Leuze safety automation spare widely used for press, packaging machine and robot workstation safety guarding replacement.
