BAUMULLER 214824 Motor Internal Terminal Assembly

Technical Specifications

Model: 214824 Brand: BAUMULLER (Baumüller, Germany) Product Type: Servo Motor Internal Terminal Assembly Mounting: Installed inside BAUMULLER servo motor housing Operating temperature: 0℃ ~ +60℃ Storage temperature: -20℃ ~ +70℃ Relative humidity: 5%~95%, non-condensing Protection: IP20 (when fully assembled inside motor casing)

System compatibility

214824 is original spare part for BAUMULLER servo motors. It is compatible with corresponding b maXX servo drive systems, applied to printing, textile, plastic and metal forming machinery for motor overhaul.

Function

214824 is the internal terminal assembly of Baumüller servo motor. It connects motor winding leads, brake wiring and temperature sensor cables, provides stable wiring transition inside the motor. It is used to replace burnt, cracked or aged terminal components during motor repair.

Installation

Disconnect all power before maintenance. Open servo motor housing, remove old terminal assembly. Fit 214824, connect winding wires according to wiring diagram, secure terminals. Reassemble motor casing, check insulation resistance, test motor running before formal production.

Interface

Motor winding terminals, brake and temperature sensor wiring pins for 214824 BAUMULLER terminal assembly.

Feature

Original Baumüller terminal assembly, high temperature resistant insulation, compact layout, vibration resistant, industrial anti-interference design. This legacy spare part used for field maintenance of old BAUMULLER servo motors.

Diagnostic

Motor insulation failure after replacement: check terminal insulation and wire stripping length for 214824. Motor overheating alarm: inspect terminal tightening torque and contact resistance. Intermittent phase loss fault: verify wiring sequence and terminal fastening.

Product Brief

214824 is German BAUMULLER servo motor internal terminal assembly. It serves as wiring transition for motor windings, brake and temperature signals, classic spare part for legacy BAUMULLER servo motor overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
