BAUMULLER 25-30/60-30-00 1 Servo Motor Resolver

Technical Specifications

Model: 25-30/60-30-00 1 Brand: BAUMULLER (Baumüller, Germany) Product Type: Servo Motor Rotary Resolver Working principle: Electromagnetic induction rotary transformer Mounting: Shaft-coupled installation on servo motor rotor rear side Operating temperature: -20℃ ~ +80℃ Storage temperature: -20℃ ~ +85℃ Relative humidity: 5%~95%, non-condensing Protection: IP54 when assembled inside motor housing Weight: 0.36kg

System compatibility

25-30/60-30-00 1 is an original resolver for BAUMULLER servo motors, matching b maXX series servo drives. Widely used for maintenance of printing, plastic extrusion, textile and metal forming machinery.

Function

This resolver is mounted on the rear of the servo motor rotor. It uses electromagnetic induction to detect real-time rotor angle and rotation speed, and transmits analog feedback signals to the servo drive. The drive relies on these signals to realize motor commutation and precise positioning control. It is used to replace faulty resolvers during motor overhaul.

Installation

Cut off all power of the servo system before disassembly. Remove the motor rear end cover, align the resolver with the motor rotor shaft, fix the mounting screws. Reconnect the resolver signal cable to the drive control board. Complete position offset calibration, test motor operation before formal production.

Interface

Excitation winding terminals, sine/cosine signal output terminals, flange mounting holes for BAUMULLER 25-30/60-30-00 1 resolver.

Feature

BAUMULLER original resolver, no optical components, strong shock and vibration resistance, high temperature resistance, suitable for dusty industrial environments, EMC anti-interference design. This legacy spare part is used for position feedback maintenance of old BAUMULLER servo motors.

Diagnostic

Drive resolver feedback alarm: check resolver wiring and shaft coupling alignment for 25-30/60-30-00 1. Motor positioning inaccuracy: inspect winding integrity and signal amplitude. Intermittent speed jitter: check cable shielding and connector pin contact.

Product Brief

25-30/60-30-00 1 is German BAUMULLER rotary resolver for servo motor. It provides rotor angle and speed feedback for closed-loop motion control, classic spare part for legacy BAUMULLER servo motor overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
