Bently Nevada 20-12-01-01-00-00-02 Proximity Probe

Feature & Principle

It is an eddy current proximity sensor. The probe head emits high-frequency alternating magnetic field. When the conductive metal shaft approaches, eddy current is generated on the target surface, which changes the coil impedance. The signal variation reflects the distance between probe and shaft. It is non-contact measurement, suitable for high-speed rotating shaft vibration and thrust position monitoring. It works together with matching extension cable and monitor module.

Specifications

Model: 20-12-01-01-00-00-02 Brand: Bently Nevada Measurement principle: Eddy current Measured target: Conductive metal rotor Output: Compatible with 3300 / 3500 monitoring system Installation: Thread mounting Application: Turbine, compressor, pump, gearbox shaft vibration and axial displacement monitoring Certification: CE

Components & Diagnostics

Probe head, internal coil, insulating housing, integrated cable, connector. Common faults: cable breakage, coil short circuit, signal loss, measurement drift.

Product Brief

20-12-01-01-00-00-02 eddy current proximity probe, Bently Nevada rotating machinery monitoring spare widely used for turbine and compressor overhaul and replacement.
