BLD590 Vertical Cycloidal Gear Reducer

Feature & Principle

It is BLD series vertical flange type cycloidal pinwheel reducer. It adopts planetary cycloidal pin engagement transmission principle. The eccentric sleeve drives cycloidal wheel for planetary motion, and the pin wheel meshes to realize large reduction ratio. The vertical flange structure is convenient for direct connection with motor, compact size, strong overload capacity, good anti-shock performance, low noise. It can realize stable speed reduction and torque amplification, suitable for continuous operation under heavy load condition.

Specifications

Model: BLD590 Type: Vertical flange cycloidal pinwheel reducer Series: BLD Installation: Vertical flange direct mount Transmission form: Single stage cycloidal Lubrication: Gear oil lubrication Housing material: Cast iron Applicable power: Match different motor power according to actual configuration Application: Mixer, reactor, conveyor, chemical stirring equipment, packaging machinery Certification: CE

Components & Diagnostics

Cast iron housing, eccentric bearing, cycloidal wheel, pin wheel housing, output shaft, oil seal. Common faults: oil leakage, bearing damage, abnormal noise, output shaft stuck, cycloidal wheel wear.

Product Brief

BLD590 cycloidal reducer, B series vertical reduction gearbox spare widely used for stirring and conveying equipment overhaul and replacement.
