C1-70-A00 Pneumatic Control Valve

Feature & Principle

It adopts air pilot control structure. The pilot air pushes the internal spool to switch flow passage, changes the direction of air circuit, and drives the actuator to move. It can realize remote pneumatic interlock control, widely used for auxiliary air path switching of mechanical equipment.

Specifications

Model: C1-70-A00 Type: Pilot pneumatic valve Medium: Compressed air, clean water, light oil Seal: NBR Control pressure: 0.3~0.7MPa Connection: Thread port Protection: IP54 Certification: CE

Components & Diagnostics

Pilot spool, valve body, sealing gasket, return spring, flow channel assembly. Common faults: spool stuck, internal air leakage, no switching action, external leakage, spring fatigue.

Product Brief

C1-70-A00 pneumatic control valve, fluid control spare widely used for packaging machinery, conveyor and pneumatic fixture air circuit control.
