Yokogawa AAI543-H61 Analog Output HART Module

Feature & Principle

It receives digital control commands from the DCS controller, converts them into isolated 4-20mA analog output signals, superimposed with HART digital signal for instrument remote parameter setting and diagnosis. It supports channel open circuit detection and redundant hot swap configuration, provides stable regulating output for flow, pressure and temperature closed-loop control loops.

Specifications

Model: AAI543-H61 Brand: Yokogawa System: CENTUM VP / CS3000 Channel: 16 isolated analog output Signal: 4-20mA, HART compatible Load resistance: 0~750Ω Isolation: Channel-to-system isolation Power supply: 24VDC Installation: Rack plug-in, hot swappable Certification: CE, IEC

Components & Diagnostics

Signal isolation circuit, D/A conversion chip, HART modem, backplane bus interface, status LED indicator. Common faults: output drift, open wire alarm, HART communication failure, channel no output, module offline.

Product Brief

AAI543-H61 AO module, Yokogawa DCS spare widely used for petrochemical, power and chemical plant CENTUM VP control cabinet maintenance.
