E-P5-S5-H-E-M-C-P-SN-D-N Pressure Transmitter Item

Feature & Principle

It is a configurable smart pressure transmitter, the string E-P5-S5-H-E-M-C-P-SN-D-N is the complete ordering code, each segment defines pressure type, range, wetted material, signal output, display, process connection, certificate and electrical connector. It adopts isolated piezoresistive sensing core, converts process pressure into 4-20mA analog signal superimposed with HART digital signal. Users can use HART communicator for remote parameter setting, zero and span calibration, self-diagnosis reading. With anti-vibration and anti-corrosion design, it supports long-term stable online pressure monitoring.

Specifications

Model: E-P5-S5-H-E-M-C-P-SN-D-N Power supply: 24VDC Signal output: 4-20mA + HART7, 2-wire Wetted material: 316L stainless steel Display: Local LCD display Process connection: Thread type defined by order code Protection class: IP67 Calibration: Local adjustment / remote HART configuration Medium: Non-corrosive gas, liquid Application: Petrochemical, water treatment, power, general industrial process pipeline Certification: CE

Components & Diagnostics

Piezoresistive sensing element, HART mainboard, stainless steel isolation diaphragm, wiring connector, LCD display module. Common faults: sensor drift, HART communication interruption, diaphragm damage, no output, thread sealing leakage.

Product BriefE-P5-S5-H-E-M-C-P-SN-D-N smart HART pressure transmitter, process pressure monitoring spare widely used for pipeline and process equipment overhaul and replacement.
