E-P5-S5-H-E-M-C-P-SN-D-N Pressure Transmitter

Feature & Principle

It is a code-type configurable smart pressure transmitter. The full string E-P5-S5-H-E-M-C-P-SN-D-N is the order code, defining pressure range, material, signal output, process connection, display, certification and electrical connector. It uses piezoresistive sensing core with isolated metal diaphragm, converts process pressure to 4-20mA analog signal superimposed with HART digital protocol. It supports remote parameter configuration, zero/span trimming and diagnostic reading via HART communicator. Anti-shock and anti-corrosion structure, suitable for continuous pressure monitoring in petrochemical, water treatment and energy pipelines.

Specifications

Model: E-P5-S5-H-E-M-C-P-SN-D-N Power supply: 24VDC Output: 4-20mA + HART Wetted material: 316L stainless steel Communication protocol: HART 7 Process connection: Thread type defined by suffix code Protection class: IP67 Calibration: Local or remote HART adjustment Application: Petrochemical, water supply, energy, general process pipeline pressure monitoring Certification: CE

Components & Diagnostics

Piezoresistive sensing element, HART signal board, stainless steel isolation diaphragm, wiring connector, local display option. Common faults: sensor drift, HART communication failure, diaphragm damage, output no response, sealing leakage.

Product Brief

E-P5-S5-H-E-M-C-P-SN-D-N smart HART pressure transmitter, process pressure measurement spare widely used for pipeline and process equipment overhaul and replacement.
