Eaton HKD3200F K-Frame MCCB Frame Unit

Feature & Principle

This breaker frame provides mechanical base and conductive structure for trip unit installation. It cooperates with matched trip unit to realize overload and short circuit protection. It adopts compact K-frame design for MCC, switchboard and panel board applications.

Specifications

Model: HKD3200F Brand: Eaton Series: Series C Frame type: K-frame Poles: 3P Rated current: 200 A Rated voltage: 600VAC, 250VDC Structure: Frame only, trip unit sold separately Mounting: Fixed type Certification: UL, CSA, IEC

Components & Diagnostics

Insulating housing, main conductor, contact support, operating mechanism base, terminal lugs (optional). Common faults: mechanism jamming, insulation aging, conductive part overheating.

Product Brief

HKD3200F circuit breaker frame, Eaton low voltage power spare widely used for industrial distribution cabinets and motor control center assembly.
