Feature & Principle

It is Eltra Q series optical incremental rotary encoder. It converts shaft rotation into A/B/Z quadrature pulse signals for speed and position monitoring. Hollow shaft structure enables direct mounting on motor shaft, simple installation. Push-pull output provides strong anti-interference capability for long distance signal transmission. Stable optical sensing design fits continuous operation in general industrial automation equipment.

Specifications

Model: Q24025PG512C Brand: Eltra Resolution: 512 PPR Shaft type: Hollow shaft Output: Push-pull Supply voltage: 5-24 VDC Max speed: 6000 RPM Ingress protection: IP54 Application: Packaging machine, textile machine, conveyor, servo feedback Certification: CE

Components & Diagnostics

Optical code disc, photoelectric receiver circuit, hollow shaft bearing assembly, signal processing PCB, cable connector. Common faults: pulse missing, unstable signal, code disc contamination, internal bearing wear, wiring failure.

Product Brief

Q24025PG512C incremental encoder, Eltra Q series rotary feedback spare widely used for automation equipment overhaul and replacement.
