Teledyne Oldham GD10-P00 Gas Detector

Feature & Principle

It is Teledyne Oldham GD10-P00 infrared point gas detector. It adopts dual-wavelength infrared absorption principle to detect combustible hydrocarbon gas or carbon dioxide. It can automatically identify optical window pollution and send pre-fault alarm. Built-in HART 7 communication supports remote calibration and diagnostic check. Explosion-proof housing is suitable for oil, gas and chemical hazardous zones, stable for continuous gas concentration monitoring.

Specifications

Model: GD10-P00 Brand: Teledyne Oldham Detection principle: Dual wavelength infrared Output: 4-20mA, HART 7 Response time: ≤5s Cable entry: M20 Ex e gland Ingress protection: IP66 Certification: ATEX, IECEx optional Application: Oil & gas platform, refinery, chemical plant, hazardous area gas monitoring

Components & Diagnostics

IR light source, optical measurement chamber, photoelectric receiver, signal processing board, explosion-proof housing, wiring terminal. Common faults: lens contamination, light source aging, signal loss, communication failure, calibration drift.

Product Brief

GD10-P00 infrared gas detector, Teledyne Oldham fixed gas monitoring spare widely used for petrochemical hazardous area overhaul and replacement.
