Emerson 1C31157G02 Ovation SOE Digital Input Personality Module

Technical Specifications

Model:1C31157G02

Brand:Emerson

Product Type:125VAC DC SOE Digital Input Personality Module

Applicable System:Emerson Ovation distributed control system thermal power plant DCS control cabinet

Matching Module:1C31127G01 digital input electronics module

Channel quantity:16 SOE discrete input channels

Input signal type:125VAC or 125VDC field contact input

Input voltage range:0‑125VAC 0‑125VDC

Time‑stamp resolution:1 millisecond event capture

Isolation:1000VAC field‑to‑logic side galvanic isolation

Input filter:Hardware debounce configurable on host electronic module

Installation:Plug‑in install with 1C31127G01 on Ovation I/O base

Common Revision:G02 hardware revised version

Status Indicator:No independent LED indicator shares status LED of host electronic module

Built‑in Function:Field 125VAC DC SOE input channel configuration high‑speed event timestamp capture surge interference suppression overvoltage protection cooperate with host module record breaker trip protection relay and high‑voltage cabinet action events

Working Temperature:0℃ ~ +60℃

Storage Temperature:‑40℃ ~ +85℃

Protection Class:IP20

Weight:0.13kg

Product Brief:

1C31157G02 is Emerson Ovation high‑voltage SOE digital input personality module G02 hardware revision works paired with 1C31127G01 electronic module

It is plugged onto I/O base together with host module defines 16‑channel sequence‑of‑events interface for 125VAC DC field discrete signal acquisition

This personality module is designed for power plant high‑voltage auxiliary circuit event recording captures contact‑action events with 1ms time‑stamp resolution for post‑fault analysis

It adapts 125VAC and 125VDC contact signals widely used for breaker auxiliary contacts trip relay feedback and high‑voltage cabinet status recording

1000VAC galvanic isolation separates high‑voltage field side from DCS logic backplane suppresses ground‑loop interference and transient surge damage

It transfers field discrete status and event timestamp data to host electronic module for signal filtering and backplane data transmission

No extra software configuration required after correct physical installation host module identifies personality hardware automatically

Shares hot‑swap channel diagnosis and surge suppression features from matched 1C31127G01 electronic module

This is EOL discontinued spare part widely used for maintenance and renovation of thermal power plant Ovation DCS system

Please confirm matching host module model before purchase

Strict ESD anti‑static protection shall be followed during installation and replacement
