EPCOS B821.C2000H Common Mode Choke

Feature & Principle

It is EPCOS through-hole common mode choke. Two groups of windings are wound on the same magnetic core. The differential mode signal generates offset magnetic field and will not be attenuated; common mode interference signal generates superposed magnetic field to form high impedance, so as to filter common mode noise. It can restrain high-frequency interference on power lines and signal cables, reduce EMC electromagnetic radiation, protect PLC, servo and other sensitive control components.

Specifications

Model: B821.C2000H Brand: EPCOS (TDK) Type: Common mode choke Installation: Through hole pin type Application: Inverter, servo drive, control cabinet EMC rectification Certification: CE, RoHS

Components & DiagnosticsFerrite magnetic core, enameled wire winding, plastic skeleton, pin terminal. Common faults: winding open circuit, insulation breakdown, magnetic core cracking.

Product Brief

B821.C2000H common mode choke coil, EPCOS EMC filter spare widely used for servo and frequency conversion cabinet overhaul and replacement.
