Extreme Networks 700119-00-05 Black Diamond MSM-48 Management Supervisor Module

Technical Specifications

Model：700119-00-05 (MSM-48) Brand：Extreme Networks Product Type: Hot-swappable supervisor / management control module for Black Diamond modular chassis

Ports & Indicators:

• Out-of-band Ethernet management port

• RJ45 console port for local CLI configuration

• USB port for firmware upload

• LED indicators for status, active/standby, fault and heartbeat alarm

Interface & Backplane:

• High-speed backplane connector to communicate with chassis switching fabric and line cards

• Supports redundant supervisor deployment (active/standby)

• Hot swap capable, replace module without chassis power off

Switching & Management Features:

• Centralized control plane for entire Black Diamond chassis

• Handles chassis management, protocol processing, routing table calculation

• MAC Address Table: 128K entries

• Max Jumbo Frame: 9216 bytes

• VLAN: Up to 4094 802.1Q tagged VLAN

• Routing: IPv4 / IPv6 static & dynamic routing protocols

• Security: 802.1X, ACL, storm control

• QoS: Hardware L2-L4 classification, 8 priority queues

• OS: ExtremeWare / EOS operating system

Power & Mechanical:

• Powered via chassis backplane

• Cooling: Dependent on chassis fan tray airflow

• Operating temperature：0℃ ~ +40℃

• Standard Black Diamond supervisor card form factor

• Weight: Approx 1.2 kg

System compatibility

700119-00-05 belongs to Extreme Black Diamond modular switch family. It is the MSM-48 supervisor module, compatible with Black Diamond chassis and matching series line cards. Supports active/standby dual supervisor redundancy. Designed for enterprise campus core and large building aggregation chassis platforms. Widely used for chassis control plane upgrade and spare replacement.

Function

700119-00-05 MSM-48 supervisor module is the main control unit for Extreme Black Diamond modular chassis. It manages all line cards in the chassis, calculates routing tables, runs network protocols and provides centralized configuration and monitoring. Redundant supervisor deployment avoids single point of failure for critical core network. Hot swap function allows online replacement without powering down the whole chassis. It supports large scale VLAN segmentation, advanced ACL and QoS for stable campus core network operation. Widely deployed for large enterprise campus and data center core chassis spare replacement.

Installation

Follow ESD protection procedure. Insert 700119-00-05 supervisor module into empty chassis slot and tighten locking screws. Power on chassis. The module will initialize and synchronize configuration with standby supervisor if deployed. Access console port to verify module status, upload firmware and configure chassis global policy. Check module heartbeat and fault LED status after boot complete.

Interface

OOB management port,RJ45 console port,USB port,status LED indicators,high-speed backplane connector for Extreme Networks 700119-00-05.

Feature

Original Extreme Networks 700119-00-05 MSM-48 supervisor management module for Black Diamond chassis,hot swappable,supports active/standby redundancy,centralized chassis control and routing processing. This spare unit is used for Black Diamond modular core switch control plane maintenance and hardware replacement.

Diagnostic

Module not detected: Check card fully seated and locking screws secured. Module fail to boot: Verify chassis power and fan tray normal operation. Configuration sync failure: Confirm firmware version matches between active and standby supervisor. Heartbeat fault alarm: Inspect backplane slot and environmental temperature. Cannot access CLI: Check console cable and terminal settings.

Product Brief700119-00-05 is Extreme Networks Black Diamond MSM-48 supervisor management module, hot-swappable, supports redundant active/standby deployment,classic spare for large modular core switch chassis.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
