Extreme Networks KT2006-0224 AC Power Supply Module

Technical Specifications

Model：KT2006-0224 Brand：Extreme Networks Product Type: Hot-swappable AC power supply module for S-series modular switch chassis

Power Input:

• 100-240V AC, 50/60Hz wide-range alternating current input

• Rated output power: 2000W

• Built-in over-voltage, over-current, over-temperature and short-circuit protection

Indicator & Interface:

• LED indicators for power ready, operating status and fault alarm

• Chassis backplane power & signal connector

• AC power inlet port

Mechanical & Environmental:

• Hot swap support, online replacement without chassis power shutdown

• Operating temperature：0℃ ~ +40℃

• Standard S-series chassis PSU form factor

• Weight: Approx 2.6 kg

System compatibility

KT2006-0224 belongs to Extreme S-series chassis power accessory family. It fits S1, S3, S4, S6, S8 modular core switch chassis. Multiple PSUs can be installed to realize N+1 redundant power architecture. Widely used for data center core aggregation and enterprise campus core network spare replacement.

Function

KT2006-0224 is high-power hot-swappable AC power module manufactured by Extreme Networks. It supplies stable power to chassis backplane, line cards and fan trays of S-series core switch. Integrated multi-layer protection circuit prevents equipment damage under abnormal electrical conditions. Hot swap design enables maintenance without shutting down the whole core network. Redundant power deployment eliminates single point of power failure. Widely deployed for data center and large campus core network spare replacement.

Installation

Follow ESD protection procedure. Slide KT2006-0224 power module into empty PSU slot of S-series chassis and lock the latch. Connect AC power cord. Check LED indicator status after power on. Verify power module status on EOS management console.

Interface

AC power inlet,chassis backplane power & signal connector,status LED indicators for Extreme Networks KT2006-0224.

Feature

Original Extreme Networks KT2006-0224 S-series chassis 2000W AC power supply module,hot swappable,multi-protection circuit,N+1 redundant power support. This spare unit is used for modular core switch power system maintenance and hardware replacement.

Diagnostic

Module no power: Check AC power cord connection and input power source. Power fault alarm: Inspect fault LED, check over-temperature or overload status. Module not detected: Confirm module fully seated in chassis PSU slot and backplane contact. Overload warning: Reduce total chassis load or add additional redundant PSU.

Product BriefKT2006-0224 is Extreme Networks hot-swappable 2000W AC power supply module for S-series modular core switch chassis, multiple electrical protection and N+1 redundancy,classic spare for datacenter core network power system.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
