Extreme Networks 7GR4280-19 Matrix N-Series Gigabit I/O Module

Technical SpecificationsModel：7GR4280-19 Brand：Extreme Networks (Legacy Enterasys) Product Type: Hot-swappable L2/L3/L4 I/O line card for Matrix N modular chassis switch

Front Ports:

• 16 × 10/100/1000BASE-T RJ45 gigabit copper ports

• Individual port link/activity LED indicators plus module health status LED

Switching Capacity: 320 Gbps Forwarding Rate: 236.8 Mpps MAC Address Table: 64K entries Max Jumbo Frame: 9216 bytes VLAN: Up to 4096 802.1Q tagged VLANs Routing: Static routing, OSPF, BGP, PIM multicast routing QoS: L2-L4 hardware classification, 8 priority queues per port Power Consumption: 120W maximum Software OS: Enterasys DFE Platinum firmware Operating temperature：0℃ ~ +50℃ Humidity: 5%~95% non-condensing Installation: Hot-swappable, insert into Matrix N chassis slot Weight: Approx 2.6 kg

System compatibility

7GR4280-19 belongs to Enterasys Matrix N DFE Platinum series. Designed for Matrix N modular chassis. Compatible with other Matrix N family I/O modules and fabric controller cards. Used in enterprise campus core and aggregation chassis for gigabit copper access port expansion.

Function

7GR4280-19 is 16-port gigabit copper hot-swappable line card for Matrix N chassis. It provides 16 copper gigabit interfaces to connect servers, workstations and access switches. DFE Platinum hardware engine delivers wire-speed Layer2 switching, Layer3 routing and Layer4 ACL/QoS processing. Hot-swap design allows module replacement without chassis power shutdown, minimizing network downtime. Supports multicast routing and advanced security ACL policy. Widely deployed in large campus core, hospital and enterprise aggregation network.

InstallationFollow ESD protection procedure. Insert I/O module into empty Matrix N chassis slot and tighten captive retaining screws. Plug RJ45 copper cables to front ports. Verify module detection via chassis CLI, configure VLAN, routing and ACL/QoS policy. Test port negotiation status after power-up.

Interface16 × GE RJ45 ports,per-port LED indicators,module status LED,backplane connector,captive retaining screws for Extreme Networks 7GR4280-19.

FeatureOriginal Extreme Networks 7GR4280-19 Matrix N DFE Platinum line card,16×1GBASE-T copper ports,hot-swappable,wire-speed L2/L3/L4 processing,64K MAC table,hardware QoS and ACL support. This spare module is used for Matrix N chassis port expansion and core network hardware maintenance.

DiagnosticModule undetected: Confirm module fully seated, tighten retaining screws, verify firmware compatibility with chassis controller. Copper port link down: Inspect cable quality and auto-negotiation configuration. Broadcast storm: Tune storm-control parameters and QoS queue scheduling. Overheat alarm: Check chassis fan tray and internal airflow. ACL abnormal: Verify hardware TCAM resource availability.

Product Brief7GR4280-19 is Extreme Enterasys Matrix N series 16-port gigabit copper hot-swappable I/O line card,classic spare for enterprise core and aggregation chassis network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
