Extreme Networks CFP2 Optical Transceiver Module

Technical SpecificationsModel:CFP2 Brand:Extreme Networks Product Type:Hot-pluggable optical transceiver module Data rate:100Gbps (112Gbps gross rate) Electrical interface:104-pin edge connector Form factor:Half width of original CFP module Common variants:

• 100GBASE-SR10:MMF,100m,MPO connector,Extreme part number 10331

• 100GBASE-LR4:SMF,10km,Duplex LC connector

• CFP2-DCO / ACO coherent:long haul DWDM Management:MDIO interface,DOM digital optical monitoring Power consumption:Typical 8–16W for 100G client-side modules Operating temperature:0℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:10%~90%, non-condensing Weight:0.25 kg

System compatibilityCFP2 is qualified by Extreme Networks for BlackDiamond X8 series line cards including BDXB-100G4X-XL. It works with ExtremeXOS operating system. It supports 100G Ethernet and OTU4 for data center core uplink and carrier transport networks.

FunctionCFP2 converts high-speed electrical signals to optical signals for 100G fiber transmission. It supports DOM to monitor real-time parameters including transmit power, receive power, module temperature and supply voltage. Some models support breakout into 10×10G ports for flexible port utilization. Used for 100G interconnection between Extreme core switches and routers.

InstallationHot-swappable insertion into CFP2 slot on Extreme line card. Align the module and push fully until latches lock. Connect optical fiber cables to the optical connector. Verify module recognition, DOM data and optical link status on ExtremeXOS before putting into production.

Interface104-pin electrical edge connector, optical port (LC or MPO), module status LEDs, ejector latches for Extreme Networks CFP2 transceiver.

FeatureOriginal Extreme Networks qualified CFP2 MSA hot-pluggable 100G optical module, smaller form factor than CFP, high port density, real-time DOM monitoring, multiple reach options for multimode/single-mode/coherent long-haul, built-in self-diagnostic function. This spare supports high-density 100G uplink deployment in large data center core networks.

DiagnosticModule not detected: check insertion, slot compatibility and ExtremeXOS firmware version. No optical link: inspect fiber cable, clean optical connectors, verify module reach matching fiber type. DOM no data: confirm Extreme validated CFP2 transceiver. Over-temperature alarm: check chassis fan airflow.

Product BriefCFP2 is Extreme Networks qualified MSA-standard hot-pluggable 100G optical transceiver module, smaller footprint than CFP, available in SR10/LR4 and coherent DWDM versions, classic spare part for data center 100G core uplink overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
