Extreme Networks Summit X460-24XDC Gigabit SFP Managed Switch

Technical SpecificationsModel:X460-24XDC Brand:Extreme Networks Product Type:1U rackmount stackable Layer2/Layer3 managed switch (non-PoE,DC power version) Ports:

• 24 ×1000BASE-X SFP gigabit fiber ports

• 4 ×10GBASE-X SFP+ high-speed uplink/stacking ports Switching capacity:176Gbps Forwarding rate:130.9Mpps MAC address table:32000 entries VLAN:4094 VLANs Jumbo frame:9216 bytes Stacking:SummitStack, up to 8 switches stacked OS:ExtremeXOS Management interfaces:RJ45 serial console port,10/100 out-of-band management port Power & fan:Hot-swappable 48V DC redundant PSU slots,hot-swappable fan tray,front-to-back airflow Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:5.2kg

System compatibilityX460-24XDC belongs to Extreme Networks Summit X460 enterprise fiber access family,DC power variant. Compatible with Extreme validated 1G SFP and 10G SFP+ transceivers SX/LX/SR/LR. Can stack with other X460 series switches. Designed for telecom room and industrial sites with 48V DC power supply. Widely used for enterprise long-distance fiber access spare replacement.

FunctionX460-24XDC is stackable Layer3 fiber switch powered by 48V DC. 24 SFP ports connect to remote building end devices; four SFP+ ports provide 10G uplink to aggregation switches. It supports wire-speed Layer2 switching,Layer3 routing,VLAN,STP/RSTP/MSTP,LACP link aggregation,ACL,QoS and multicast snooping. It monitors optical module DDM,port link status,system temperature,DC power and fan health, and sends hardware fault alarms. Used for enterprise campus and telecom environment fiber edge networks.

InstallationMount the switch on standard 19-inch 1U rack. Install hot-swappable 48V DC power supplies and fan tray. Insert SFP/SFP+ transceivers and fiber patch cords. Install stacking module if required. Connect console port for ExtremeXOS configuration. Verify boot,port optical link and stacking function before commissioning.

Interface24×1G SFP slots,4×10G SFP+ uplink/stacking ports,RJ45 serial console,out-of-band management port,status LEDs,reset button,rear stacking/option card slot,48V DC redundant PSU slots,fan tray,ground terminal,rack mounting ears for Extreme Networks Summit X460-24XDC.

FeatureOriginal Extreme Networks Summit X460 1U rackmount DC-powered fiber switch,24 fixed 1G SFP fiber ports plus quad 10G SFP+ uplink,hot-swappable redundant 48V DC PSU and fan tray,DDM optical monitoring,stacking capability,ExtremeXOS operating system,built-in self-diagnostic function. This spare supports enterprise and telecom site fiber edge network deployment with DC power infrastructure.

DiagnosticSwitch fails to boot: check 48V DC input voltage and PSU module health. Fiber port link down: verify SFP/SFP+ transceiver, fiber cable and port admin status. Low optical power alarm: dirty fiber endfaces or damaged fiber cable. Transceiver undetected: confirm Extreme validated optical module and proper insertion. Over-temperature alarm: check fan tray operation and rack airflow,remove dust buildup. Stacking port down: verify matching ExtremeXOS firmware and stacking cable integrity.

Product BriefX460-24XDC is Extreme Networks Summit X460 series 1U rackmount Layer3 stackable DC-powered fiber managed switch with 24×1G SFP and 4×10G SFP+ uplink ports,classic spare part for enterprise and telecom fiber edge access network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
