Extreme Networks WS-AP3917i-ROW Indoor Wi-Fi 6 Access Point

Technical Specifications

Model：WS-AP3917i-ROW Brand：Extreme Networks Product Type: Enterprise indoor Wi-Fi 6 wireless access point (ROW global region version)

Radio & Antenna:

• Wi-Fi 6 (802.11ax): 2.4GHz radio + 5GHz radio

• Integrated IoT radio: BLE / 802.15.4 for IoT sensor connectivity

• 5 built-in internal antennas, no external antenna required

• Optional GPS receiver (activated by firmware)

Ports & Indicators:

• 2 × 10/100/1000BASE-T RJ45 Gigabit Ethernet ports

• RJ45 console port for local management

• Reset button for factory restore

• 4 status LED indicators for power, radio, link and fault alarm

Power Supply:

• Powered by IEEE802.3af / IEEE802.3at PoE

• No dedicated AC power adapter required

Mechanical & Environmental:

• Indoor enclosure design

• Operating temperature：0℃ ~ +50℃

• Wall or ceiling mounting bracket support

• Weight: Approx 1.0 kg

Wireless & Security Features

• Max Jumbo Frame: 9216 bytes

• SSID: Multiple SSID support for network segmentation

• Security: WPA2, WPA3, 802.1X authentication, MAC filtering

• QoS: Wi-Fi Multimedia WMM, hardware priority queue

• Management: Managed by ExtremeCloud IQ / ExtremeWireless controller

• Fabric Attach compatible for Extreme Fabric network

System compatibility

WS-AP3917i-ROW belongs to Extreme AP3900 wireless AP family. ROW version for global regions (excluding FCC North America). Compatible with ExtremeCloud IQ controller and ExtremeWireless wireless management platform. Works with Extreme PoE switches such as X465, X460-G2, V400 series. Widely used for enterprise office, smart campus, retail store and industrial indoor wireless network spare replacement.

Function

WS-AP3917i-ROW is indoor enterprise Wi-Fi6 access point manufactured by Extreme Networks. It delivers high-speed Wi-Fi6 wireless coverage for large indoor spaces. Integrated BLE/IoT radio supports asset tracking and IoT sensor connection. Dual gigabit ports provide flexible uplink and cascading options. It supports centralized cloud or wireless controller management, WPA3 secure encryption and multi-SSID isolation. Powered by PoE simplifies cabling for ceiling and wall installation. Widely deployed for smart building, campus and retail wireless network spare replacement.

Installation

Follow ESD protection procedure. Fix AP bracket on ceiling or wall, clip WS-AP3917i-ROW onto mounting bracket. Connect Ethernet cable to PoE switch port. Power up via PoE. Adopt AP into ExtremeCloud IQ or wireless controller, configure SSID, security policy and radio parameters. Verify wireless client access status.

Interface

2×GE RJ45 ports,RJ45 console port,reset button,status LED indicators,internal antennas for Extreme Networks WS-AP3917i-ROW.

Feature

Original Extreme Networks WS-AP3917i-ROW indoor Wi-Fi6 AP,ROW global regulatory domain,2.4G+5G Wi-Fi6 plus BLE IoT radio,dual gig ports,PoE powered,cloud/controller managed. This spare unit is used for enterprise indoor wireless coverage maintenance and hardware replacement.

Diagnostic

AP cannot boot: Check PoE switch power supply and Ethernet cable. Wireless clients cannot associate: Verify SSID, WPA3/WPA2 security configuration and radio regulatory profile. No IoT BLE signal: Confirm IoT radio enabled in controller configuration. AP offline: Check uplink cable, VLAN and controller network reachability. LED fault alarm: Inspect PoE power budget and environmental temperature.

Product BriefWS-AP3917i-ROW is Extreme Networks AP3917i indoor Wi-Fi6 access point for ROW global regions, built-in BLE IoT radio, dual gigabit ports and PoE operation,classic spare for enterprise indoor wireless and IoT converged network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
