Extreme Networks X460-G2-24t-24x Gigabit Mixed Media Managed Switch

Technical SpecificationsModel:X460-G2-24t-24x Brand:Extreme Networks Product Type:1U rackmount stackable Layer2/Layer3 managed switch (non-PoE) Ports:

• 24 ×10/100/1000BASE-T RJ45 copper ports

• 24 ×1000BASE-X SFP gigabit fiber slots

• 4 ×10GBASE-X SFP+ high-speed uplink ports (2 ports support stacking) Switching capacity:364Gbps Forwarding rate:270.8Mpps MAC address table:64000 entries Jumbo frame:9216 bytes Stacking:SummitStack-V400, up to 8 switches stacked CPU/Memory:1GHz 64-bit CPU,1GB ECC DDR3 RAM,4GB eMMC flash OS:ExtremeXOS Management interfaces:RJ45 serial console,USB console,1G out-of-band management port Expansion:Rear VIM modular uplink slot,TM clock slot for PTP/SyncE Power & fan:Dual hot-swappable PSU slots,hot-swappable fan tray,front-to-back / back-to-front airflow selectable Operating temperature:0℃ ~ +50℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:6.0kg

System compatibilityX460-G2-24t-24x belongs to Extreme Networks X460-G2 enterprise edge/aggregation family. Compatible with Extreme validated 1G SFP and 10G SFP+ transceivers including SX/LX/SR/LR and DAC cables. Can stack with other X460-G2 switches. Widely used for enterprise campus mixed copper/fiber aggregation spare replacement.

FunctionX460-G2-24t-24x is high-density mixed-media stackable Layer3 switch. It supplies 24 copper gigabit ports for local end-device access and 24 SFP fiber ports for long-distance building connections, with four 10G SFP+ uplink ports for core interconnection. It supports wire-speed Layer2 switching,Layer3 routing,PTP precision time protocol,SyncE,VLAN,STP/RSTP/MSTP,LACP/MLAG,ACL,QoS and multicast control. It monitors SFP/SFP+ DDM optical diagnostics,port link status,system temperature,power and fan health, and sends hardware fault alarms. Used for large enterprise campus mixed media aggregation networks.

InstallationMount the switch on standard 19-inch 1U rack. Install hot-swappable power supplies and fan tray. Insert SFP/SFP+ transceivers and fiber/DAC cables. Connect console port for ExtremeXOS configuration. Verify boot,port link,stacking and routing function before commissioning.

Interface24×1G RJ45 ports,24×1G SFP slots,4×10G SFP+ uplink/stacking ports,RJ45 serial console,USB console,1G out-of-band management port,status LEDs,reset button,rear VIM expansion slot,TM clock slot,dual PSU slots,fan tray,ground terminal,rack mounting ears for Extreme Networks X460-G2-24t-24x.

FeatureOriginal Extreme Networks X460-G2 1U rackmount mixed-media gigabit switch,24 copper +24 fiber high-density ports plus quad 10G SFP+ uplink,PTP/SyncE timing support,hot-swappable redundant PSU/fan,DDM optical monitoring,400G stacking capability,ExtremeXOS operating system,built-in self-diagnostic function. This spare supports enterprise campus copper & fiber mixed aggregation network deployment.

DiagnosticSwitch fails to boot: check AC power input and PSU module health. Copper port link down: inspect Cat5e/Cat6 cable quality and auto-negotiation. Fiber port no link: verify SFP transceiver, fiber cable and port admin status. Optical low power alarm: dirty fiber end faces or damaged fiber cable. Stacking port down: check SFP+ transceiver and stacking cable integrity. Over-temperature alarm: check fan tray operation and rack airflow,remove dust buildup.

Product BriefX460-G2-24t-24x is Extreme Networks X460-G2 series 1U rackmount Layer3 stackable mixed-media managed switch with 24×1G RJ45,24×1G SFP and 4×10G SFP+ uplink ports,classic spare part for enterprise mixed copper/fiber aggregation network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
