Extreme Networks XA1480 ExtremeAccess Platform 1480 Branch Appliance

Technical SpecificationsModel：XA1480 Brand：Extreme Networks Product Type: Compact x86 branch fabric gateway appliance (XA1400 series)

Front / Rear Interfaces:

• 6 × 10/100/1000BASE-T Gigabit RJ45 copper ports

• 2 × SFP+ slots, support 1G /10G transceivers, DAC and AOC cables

• 1 × RJ45 serial console port

• 1 × Micro-B USB management port

• 2 × USB-A ports for external flash storage

• Out-of-band management Ethernet port

• LED indicators for port, fan and system health

Hardware Core:

• 8-core Intel processor

• 8GB onboard RAM

• 64GB SSD local storage Max Jumbo Frame: 9216 bytes Supported Functions: Fabric Connect VPN (FCVPN), IPsec encryption, L2/L3 VSN virtual services network, static routing, BGP, MLAG QoS: Hierarchical hardware QoS for branch traffic shaping Power Supply: External 12V 60W DC power adapter (power cord sold separately) Software OS: VOSS (Virtual Operating System) Operating temperature：0℃ ~ +40℃ Dimension: 250mm × 44mm × 252mm Weight: Approx 1.7 kg Mounting: Optional 2-post rack mount kit

System compatibility

XA1480 belongs to ExtremeAccess XA1400 family, paired with XA1440. Runs VOSS, integrates seamlessly with VSP series fabric switches. Compatible with 10G SFP+ transceivers and DAC cables. Designed for branch site to extend main campus Fabric Connect over public internet or MPLS WAN.

Function

XA1480 is compact branch fabric gateway appliance for extending Extreme Fabric Connect to remote offices. It uses FCVPN and IPsec to securely stretch campus L2/L3 virtual networks across WAN links, delivering consistent policy and segmentation for remote branches. Built-in x86 hardware with SSD supports local service processing. 6 gigabit copper ports connect local branch terminals, two 10G SFP+ ports serve as uplink towards WAN or local aggregation. Small footprint fits limited space in remote site telecom cabinet. Widely used for enterprise branch, retail site and remote office fabric extension deployment.

InstallationFollow ESD protection procedure. Fix appliance on desktop or install optional rack mount bracket. Connect 12V external DC power adapter. Insert SFP+ modules or DAC cables for uplink. Access console port for initial VOSS configuration, enable FCVPN, IPsec tunnel and VSN segmentation. Verify fabric peering and tunnel encryption after power-up.

Interface6 GE RJ45 ports,2 × SFP+ slots,RJ45 serial console,Micro-B USB,2×USB-A,OOB management port,status LED indicators,DC power jack for Extreme Networks XA1480.

FeatureOriginal Extreme Networks XA1480 ExtremeAccess 1480 branch fabric gateway,compact low-profile appliance,8-core CPU,8G RAM+64G SSD,6GE+2×10G SFP+,VOSS OS,support Fabric Connect VPN and IPsec encryption. This spare appliance is used for enterprise remote branch fabric extension and WAN edge network replacement.

DiagnosticAppliance boot failure: Check 12V DC power adapter output and power cable connection. SFP+ port link down: Verify transceiver compatibility, clean fiber end and check DDM optical readings. FCVPN tunnel offline: Confirm underlay network reachability and matching VNI/IPsec parameters. SSD storage alarm: Check SSD health status via VOSS CLI. Overheat alarm: Inspect built-in fan operation and cabinet ventilation.

Product BriefXA1480 is ExtremeAccess XA1400 series compact branch fabric gateway appliance,classic spare for extending Extreme Fabric Connect to remote office WAN edge.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
