Fireye R9107A1001 Flame Amplifier Controller

Technical Specifications

Model：R9107A1001 Brand：Fireye Product Type: Rack mounted flame signal amplifier / flame monitor controller

Detection Feature:

• Compatible sensor: C9701, C9707 non-incendive flame scanners

• Flame threshold: Adjustable flame signal threshold

• FFRT (Flame Failure Response Time): Configurable response timing

• Dual gain setting: Two adjustable gain modes, selectable by external contact

• Flame failure action: De-energize flame relay once valid flame signal is lost

Electrical Parameters:

• Supply voltage: 120VAC / 240VAC selectable

• Relay output: Flame relay and marginal alarm relay

• Analog output: 0-10VDC output for remote flame strength meter

• Built-in flame meter: Onboard meter for local flame strength reading

Mechanical & Structure:

• Housing: Standard 19-inch rack mount chassis

• Mounting: 19" rack installation

• Indicator: Onboard analog flame meter, status indicators

• Terminal block: Screw type terminals for scanner and external wiring

Environmental:

• Operating temperature: -20℃ ~ +60℃

• Ambient humidity:0~85% non-condensing

• Certification: UL, FM approved

• Weight: Approx 1.65kg

System compatibilityR9107A1001 belongs to Fireye R9000 series flame amplifier family. Designed to pair exclusively with C9701 and C9707 non-incendive flame scanners. Applied for large industrial boilers, process furnaces and multi-burner combustion systems. Widely used for combustion flame monitoring system spare replacement.

FunctionR9107A1001 is rack-mounted flame signal amplifier manufactured by Fireye. It receives raw flame signal from C9701 / C9707 non-incendive flame scanners, amplifies and processes the flame signal. It provides adjustable flame threshold and configurable flame failure response time. It integrates flame relay and marginal alarm relay for burner safety interlock. 0-10VDC analog output supports remote flame strength display. Dual gain settings adapt to variable flame conditions. It continuously judges flame presence and triggers safety alarm or relay action upon flame loss. Widely deployed for large industrial boiler flame monitoring and spare replacement.

InstallationFollow lockout/tagout safety procedure before installation. Install R9107A1001 into standard 19-inch equipment rack. Run shielded cable to connect the amplifier with C9701 / C9707 scanner strictly follow Fireye R9000 series wiring schematic. Complete flame threshold calibration and FFRT setting, then perform flame signal test during commissioning.

InterfaceOnboard flame meter,status LED indicators,flame relay terminals,marginal alarm relay terminals,0-10VDC analog output,19" rack mount chassis for Fireye R9107A1001.

FeatureOriginal Fireye R9107A1001 R9000 series rack mount flame amplifier,matched with C9701 & C9707 non-incendive scanners,adjustable flame threshold and FFRT,0-10VDC analog output,UL & FM safety certified. This spare unit is used for large industrial boiler burner flame signal processing maintenance and hardware replacement.

DiagnosticNo flame reading: Inspect scanner lens contamination, scanner wiring continuity and terminal connection. Marginal flame alarm: Adjust flame threshold, check scanner alignment or flame signal attenuation. Relay no switch action: Verify amplifier power supply and flame gain configuration. Unstable analog output: Check shield cable grounding and external interference.

Product BriefR9107A1001 is Fireye R9000 series rack mount flame amplifier for C9701 / C9707 non-incendive flame scanners,with adjustable FFRT and 0-10VDC output,classic spare for large industrial burner flame monitoring system.
