Fireye SB560332AA Burner Flame Safeguard Controller

Technical Specifications

Model：SB560332AA Brand：Fireye Product Type: Microprocessor-based compact burner flame safeguard controller

Detection Feature:

• Flame sensing method: UV ultraviolet flame scanner detection

• TFI (Trial for Ignition): Selectable 5 / 10 seconds

• Pre-purge function: NO built-in pre-purge sequence

• Air proving check: Pre-purge air proving monitor

• Flame failure action: Instant safety lockout once flame signal is lost

Electrical Parameters:

• Supply voltage: 240VAC, 50/60Hz (+10/-15%)

• Max connected load: 15A

• Reset mode: Power cycle reset

• Flame signal jack: Onboard test jack for real-time flame strength reading

Mechanical & Structure:

• Housing: Red NEMA rated enclosure

• Mounting: Panel mount design

• Indicator: Multi LED status indicators for lockout, flame, interlock status

• Reset button: Manual local reset push button

Environmental:

• Operating temperature: -20℃ ~ +60℃

• Ambient humidity:0~85% non-condensing

• Certification: UL, FM approved, meets EN298 standard

• Weight: Approx 1.1kg

System compatibilitySB560332AA belongs to Fireye SB series flame safeguard family. Compatible with Fireye UV series ultraviolet flame scanners such as UV1A, UV2, UV1A12. It can be used on single gas industrial burners, commercial heating boilers and process heating equipment. Direct drop-in replacement for obsolete Eclipse VF560332XA, no rewiring required. Widely used for combustion safety system spare replacement.

FunctionSB560332AA is compact microprocessor flame safeguard controller manufactured by Fireye. It works with UV flame scanner to continuously monitor burner flame condition. It supports selectable 5/10s ignition trial timing and has no pre-purge sequence. It will immediately shut off fuel supply and trigger safety lockout if flame fails during ignition or running state. LED lights display running, fault and flame status. The onboard test jack supports on-site flame signal inspection. Widely deployed for gas boiler and furnace burner safety control and spare replacement.

InstallationFollow lockout/tagout safety procedure before installation. Mount SB560332AA on control panel. Connect UV flame scanner, fuel valve, ignition transformer and interlock wiring strictly follow Fireye SB series wiring schematic. Execute burner cycling test and flame signal strength verification during commissioning.

InterfaceUV flame signal terminals,multi-function LED indicator,manual reset push button,flame test jack,red metal enclosure for Fireye SB560332AA.

FeatureOriginal Fireye SB560332AA SB series flame safeguard controller,240VAC,UV flame scanner detection,no pre-purge,5/10s selectable TFI,UL & FM safety certified. This spare unit is used for industrial gas boiler burner flame detection maintenance and hardware replacement.

DiagnosticLockout on startup: Inspect UV scanner lens contamination,optical alignment,wiring continuity,fuel supply and ignition circuit. No flame indication: Check UV tube aging,cable shielding integrity and wiring connection. Random lockout during running: Verify burner vibration,UV cable shielding and interlock circuit. No power LED: Inspect 240VAC power supply and internal fuse.

Product BriefSB560332AA is Fireye SB series 240VAC flame safeguard controller with UV scanner input,no pre-purge and 5/10s TFI timing,direct replacement for VF560332XA,classic spare for gas burner combustion safety system.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
