Fireye YB230DC BurnerLogix Y Integrated Burner Control Chassis

Technical Specifications

Model：YB230DC Brand：Fireye Product Type: BurnerLogix Y series microprocessor burner control chassis with built-in direct-coupled DC flame amplifier

Control Feature:

• Amplifier type: Direct-coupled DC flame amplifier

• Compatible flame detector: Fireye Phoenix and InSight series flame scanners

• Sequence control: Pre-purge, ignition trial, flame supervision, post-purge and safety lockout

• Support burner modes: on/off, high-low-off and modulating burner

• Built-in valve proving function, burner runtime logging and lockout fault history

• Support flame rod, UV and IR flame signal inputs with matched scanners

Electrical Parameters:

• Supply voltage: 230 VAC, 50/60Hz

• Power consumption: 25VA

• Flame input: dedicated direct coupled flame scanner terminals

• Relay outputs: fuel valve, ignition, alarm and auxiliary relay outputs

• Digital inputs: safety interlock, airflow, pressure and temperature limit switches

• Communication: Optional Modbus RTU communication module

Mechanical & Structure:

• Mounting: DIN rail installation inside control cabinet

• Housing: NEMA1 metal chassis

• Front panel: LED status indicators, manual reset button

• Expansion slot: For plug-in YP programmer module

• Optional display: BLV512 OLED or BLL510 LCD display (sold separately)

Environmental:

• Operating temperature: -40℃ ~ +60℃

• Ambient humidity: 0~90% non-condensing

• Certification: UL, FM approved

• Weight: Approx 2.1kg

System compatibility

YB230DC belongs to Fireye BurnerLogix Y burner control family. Compatible with Fireye Phoenix, InSight flame scanners. Matches YP series programmer modules, BLV512/BLL510 display units and standard wiring bases. Suitable for gas, oil and dual-fuel boiler and furnace burners. Widely used for industrial combustion safety control spare replacement.

Function

YB230DC is BurnerLogix Y integrated burner control chassis manufactured by Fireye. It integrates burner sequencing logic and direct-coupled DC flame amplifier. The direct-coupled amplifier receives flame signals from Phoenix and InSight intelligent flame scanners without external amplifier modules. The controller manages full burner cycle including pre-purge, ignition trial, flame monitoring and post purge. When flame loss or scanner fault is detected, it triggers safety lockout and cuts fuel supply immediately to avoid unburned fuel accumulation and explosion risk. It supports valve proving, stores fault logs and burner operating hours for maintenance diagnosis. Widely deployed for industrial boilers and furnaces burner safety control spare replacement.

Installation

Follow lockout/tagout safety procedure before installation. Mount YB230DC chassis on DIN rail in control cabinet. Install YP programmer module and optional display. Wire 230VAC power, external safety interlock switches, ignition transformer and fuel valve relays. Connect Phoenix / InSight flame scanner wiring strictly following Fireye wiring schematic. Complete cold test and burner firing commissioning, verify flame signal and safety lockout function.

InterfaceAC power terminal block,direct-coupled flame scanner input terminals,digital interlock input terminals,relay output terminals,YP programmer slot,LED status indicators & reset button for Fireye YB230DC.

FeatureOriginal Fireye YB230DC BurnerLogix Y chassis,230VAC power,built-in direct-coupled DC flame amplifier,compatible with Phoenix and InSight scanners,integrated valve proving function,UL & FM safety certified. This spare unit is used for industrial boiler burner sequence and flame safety system maintenance and hardware replacement.

DiagnosticFlame lockout: Inspect flame scanner lens, optical alignment, scanner wiring and flame signal strength. Scanner communication fault: Verify Phoenix/InSight scanner compatibility and cable integrity. Interlock lockout: Check external pressure/temperature/airflow limit switches and interlock loop continuity. No power: Check 230VAC supply voltage and internal fuse integrity. Valve proving failure: Inspect fuel valve leakage, valve switch wiring and test timing parameters.

Product BriefYB230DC is Fireye BurnerLogix Y series 230VAC burner management chassis with direct-coupled DC amplifier,works with Phoenix and InSight flame scanners,provides burner sequencing and flame safety interlock,classic spare for industrial furnace combustion control system.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
