Fireye YP138 BurnerLogix Programmer Module

Technical Specifications

Model：YP138 Brand：Fireye Product Type: Plug-in programmer timing module for BurnerLogix ZB/YB series burner management chassis

Sequence Feature:

• FFRT (Flame Failure Response Time): 4 seconds

• Operation mode: Non-recycle, modulating burner control

• Core function: Indefinite pilot hold during lightoff, revert to pilot mode from automatic firing

• Air damper: Support open damper proving function

• Timing: Keypad selectable pre-purge, PTFI, MTFI and post-purge timing

• Terminal 16: Voltage applied to maintain pilot hold; revert to pilot from auto mode

Mechanical & Structure:

• Form: Plug-in card, directly inserted into YB / ZB BurnerLogix chassis programmer slot

• Installation: Power off chassis before replacement, hot swap prohibited

• Compatible chassis: ZB110, ZB230, YB110, YB230 BurnerLogix chassis

Environmental:

• Operating temperature: -40℃ ~ +60℃

• Ambient humidity: 0~90% non-condensing

• Certification: cULUS listed

• Weight: Approx 0.18kg

System compatibility

YP138 belongs to Fireye BurnerLogix YP programmer family. Compatible with ZB110, ZB230, YB110, YB230 burner control chassis. Works with UV self-check, standard UV, IR auto-check flame amplifier chassis. Matches BLV512 / BLL510 display units. Designed for gas or oil industrial boiler and furnace modulating burners. Widely used for combustion safety system spare replacement.

Function

YP138 is plug-in programmer timing module manufactured by Fireye. It defines full burner operating sequence and safety timing parameters for BurnerLogix chassis. It supports non-recycle modulating burner operation with open damper proving. It provides indefinite pilot hold during lightoff phase, and can revert automatically to pilot firing from high fire mode by terminal 16 signal. The module controls pre-purge, pilot trial for ignition (PTFI), main flame trial for ignition (MTFI) and post-purge cycle. If flame loss occurs during firing, 4s FFRT triggers safety lockout and cuts fuel supply to prevent explosion hazard. All timing parameters can be edited via BurnerLogix display. Widely deployed for gas and oil modulating boiler burner sequence control and spare replacement.

Installation

Follow lockout/tagout safety procedure before installation. Cut off power supply of BurnerLogix chassis. Insert YP138 programmer module firmly into chassis programmer slot. Restore power, configure purge timing, pilot mode and damper proving function via BLV512 or BLL510 display. Execute cold sequence test and burner firing commissioning, verify pilot hold and flame loss lockout timing.

InterfaceGold edge connector for chassis slot,terminal 16 pilot hold logic pins,sequence control logic circuit for Fireye YP138.

FeatureOriginal Fireye YP138 BurnerLogix plug-in programmer module,4 second FFRT,non-recycle modulating burner logic,indefinite pilot hold,open damper proving support,cULUS safety certified. This spare unit is used for industrial boiler burner sequence timing configuration maintenance and hardware replacement.

DiagnosticSequence wrong timing: Check YP module model match, recheck display configuration parameters. Pilot hold malfunction: Inspect terminal 16 wiring and voltage signal. No ignition output: Verify pilot/intermittent pilot setting and interlock status. Chassis cannot recognize programmer: Power down chassis, re-seat YP138 module, inspect edge connector contamination.

Product BriefYP138 is Fireye BurnerLogix series plug-in programmer module with 4s FFRT, non-recycle logic and indefinite pilot hold function, dedicated for gas/oil modulating burners, defines burner purge, ignition and safety sequence timing,classic spare for industrial furnace combustion control system.
