Foxboro 62HD‑4EJ6‑0H M/62H Single‑Loop Controller Module

Technical Specifications

Model:62HD‑4EJ6‑0H

Brand:Foxboro

System compatibility:Spec‑200 analog DCS system

Function:Single closed‑loop PI regulation for process variable control

Installation:Standard Spec‑200 rack slot,direct backplane bus connection

Control algorithm:Proportional‑Integral PI

Input signal:4‑20mA analog process variable input

Output signal:4‑20mA analog control output for field actuators

Operation feature:Bumpless auto‑manual mode switching,local set‑point adjustment

Proportional band:5‑500% adjustable

Integral time:0.01‑50 minutes adjustable

Diagnostic:On‑board LED indicators for power status and loop alarm

Environmental standard:Compliant with ISA‑S71.04 Class G3 industrial atmospheric condition

Housing:Metal shielded rack‑mount housing,anti‑vibration mechanical structure

Protection class:IP20

Horizontal operating temperature:0℃ ~ +60℃

Vertical operating temperature:‑20℃ ~ +55℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5%‑95% non‑condensing

Weight:0.51kg

Dimensions:34mm × 126mm × 142mm

Certification:CE,UL

MTBF:>89000 hours

Built‑in function

62HD‑4EJ6‑0H single‑loop PI controller receives 4‑20mA process variable signal from field transmitters and executes closed‑loop regulation. It supports local set‑point modification and bumpless auto‑manual switching to prevent output shock during mode change. Metal shield housing suppresses electromagnetic interference,stable for pressure,flow and temperature control loops in petrochemical and chemical plants.

Product Brief

62HD‑4EJ6‑0H belongs to Foxboro Spec‑200 legacy DCS spare‑part family,obsolete original automation component. Must be installed inside matching Spec‑200 instrument rack. Widely used for original Foxboro DCS equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation
