Foxboro AW51B Application Workstation Node Module

Technical Specifications

Model:AW51B

Brand:Foxboro

System compatibility:I/A Series DCS distributed control system

Function:Application workstation node hardware,undertakes process‑data calculation,alarm processing and operator‑station data interaction

Installation:Rack‑mount installation,mated with dedicated I/A‑Series node baseplate

Communication interface:Nodebus high‑speed real‑time control network interface

Processing function:Real‑time process‑data receiving,alarm event processing,historical data caching

Operation support:Provides data source for operator display,report generation and system diagnosis

Memory:On‑board non‑volatile memory,retains system node configuration parameters

Diagnostic function:Built‑in self‑test,hardware fault detection,front‑panel multi‑color LED status indication

Power supply:24VDC system bus powered

Environmental standard:Compliant with ISA‑S71.04 Class G3 industrial atmospheric condition

Housing:Metal rack‑mount housing,anti‑vibration mechanical reinforcement

Protection class:IP20

Horizontal operating temperature:0℃ ~ +60℃

Vertical operating temperature:‑20℃ ~ +55℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5%‑95% non‑condensing

Weight:1.25kg

Dimensions:42mm × 250mm × 220mm

Certification:CE,UL

MTBF:>87000 hours

Built‑in function

AW51B application workstation node acts as core hardware node for Foxboro I/A‑Series DCS system. It communicates with field control processors via Nodebus network,completes mass process‑data receiving,alarm event sorting and caching. It provides stable data source for upper‑level operator screens and report functions. Built‑in self‑diagnosis circuit monitors hardware running status,LED feedback facilitates on‑site fault inspection,widely applied for petrochemical,chemical and power‑plant DCS monitoring workstation hardware.

Product Brief

AW51B belongs to Foxboro I/A‑Series legacy DCS workstation spare‑part family,obsolete original node hardware component. Must match dedicated I/A‑Series node baseplate and Nodebus network wiring. Widely used for original Foxboro DCS‑equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation
