Foxboro FBM216 Redundant‑Ready HART Communication Analog Input Fieldbus Module

Technical Specifications

Model:FBM216(P0917XQ)

Brand:Foxboro

System compatibility:I/A Series DCS FBM200 series fieldbus I/O subsystem,works with FCP/FCM controller,can form redundant hot‑standby pair with FBM214 on adjacent baseplate slots,matched with corresponding termination assembly and pre‑terminated cable assembly

Function:Redundant‑ready group‑isolated HART‑capable analog input fieldbus module,functionally identical to FBM214,designed for redundant pairing configuration,8‑channel 4‑20.4mA analog input acquires signals from HART smart transmitters and conventional 4‑20mA instruments,per‑channel HART FSK modem for bidirectional instrument communication,sigma‑delta A/D conversion,configurable integration‑time and rate‑of‑change‑limit parameters,redundant‑pair fault‑tolerant logic for critical control loops

Installation:Baseplate‑mount installation,mated with dedicated FBM baseplate,installed in adjacent slot together with FBM214 for redundant configuration,matched with dedicated termination assembly and pre‑terminated cable assembly

Input channel:8‑channel 4‑20.4mA analog input,group‑wise galvanic isolation,nominal channel input impedance 61.9Ω,minimum total loop resistance 280Ω per channel

Circuit feature:Sigma‑delta high‑precision A/D conversion,per‑channel over‑voltage‑over‑current protection,sensor open‑circuit detection,complies with HCF_SPEC‑54 HART physical‑layer standard,max two HART digital messages per‑channel per second

Feature:Support hot‑swap online replacement without subsystem power‑off,redundant 2Mbps fieldbus communication with FCP/FCM controller,redundant‑ready hot‑standby pairing supported on adjacent baseplate slots,group‑isolated design(non‑channel‑to‑channel isolation)

Diagnostic:Front‑panel multi‑color LED indicators for power and fieldbus communication status,HART device diagnostic data and channel fault status passed to DCS system

Power supply:24VDC via FBM baseplate backplane,power consumption ≤2.5W typical

Protection:Transient surge absorption for each signal channel

Environmental standard:Compliant with ISA‑S71.04 Class G3 industrial atmospheric condition

Housing:Aluminum alloy metal housing,slot‑in mechanical locking structure

Protection class:IP20

Horizontal operating temperature:‑20℃ ~ +70℃

Storage temperature:‑40℃ ~ +85℃

Relative humidity:5%‑95% non‑condensing

Weight:0.32kg

Dimensions:45mm ×110mm ×115mm

Certification:CE,UL

Built‑in function

FBM216 redundant‑ready HART analog input module serves as hot‑standby backup partner for FBM214 in Foxboro I/A‑Series DCS critical‑loop applications. It acquires 4‑20mA analog process values and HART digital diagnostic parameters from field smart transmitters. Group‑isolation architecture improves anti‑interference performance for field signals. When deployed as FBM214/FBM216 redundant pair,automatic module switch‑over occurs upon primary module fault without process‑loop interruption. Hot‑swap supports online module replacement without system shutdown,widely applied for pressure,tank‑level and flow‑critical‑loop maintenance in petrochemical,chemical and power‑plant facilities.

Product Brief

FBM216 belongs to Foxboro I/A Series legacy DCS redundant‑ready‑HART‑analog‑input spare‑part family,obsolete original baseplate‑mount redundant‑pair HART‑communication‑input‑interface module component. Must be used in adjacent‑slot redundant‑pair configuration with FBM214 and matched termination hardware. Widely used for original Foxboro DCS equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation.
