Foxboro P0916DC Type1 Termination Cable Assembly

Technical Specifications

Model:P0916DC

Brand:Foxboro

System compatibility:I/A Series DCS FBM204,FBM2XX series I/O modules

Function:Pre‑terminated Type1 signal termination cable assembly,realizes signal connection between FBM204 mixed analog‑discrete I/O fieldbus module and field termination unit,transmits analog input and analog output process signals

Installation:Direct plug‑in connection for FBM2XX module side,mate with corresponding termination assembly

Cable parameter:3m nominal length,22AWG tinned copper conductor,braided shield,PVC insulation and jacket,pre‑assembled Type1 dedicated connectors at both ends

Circuit feature:Integral shielding design,suppress electromagnetic interference,pre‑wired factory assembly,no field wire‑crimping required

Feature:Pre‑terminated factory finished assembly,fast field installation,reduce wiring error risk

Diagnostic:No on‑board indicator,signal integrity verified by DCS module channel diagnostics

Power supply:Passive signal cable,no internal power consumption

Protection:Shielded construction for transient‑surge suppression for signal lines

Environmental:Operating temperature‑40℃ ~ +80℃,storage‑40℃ ~ +85℃,relative humidity 5%‑95% non‑condensing

Weight:0.47kg

Dimensions:Cable length 3000mm

Certification:CE,UL

Built‑in function

P0916DC Type1 termination cable transmits analog input and analog output signals between FBM204 mixed I/O module and field termination hardware for Foxboro I/A‑Series DCS system. Factory pre‑terminated connectors eliminate manual field crimping work and reduce wiring faults. Overall braided shield improves anti‑interference performance for analog process signals. Widely used for pressure,tank‑level and flow‑process‑loop wiring retrofit in petrochemical,chemical and power‑plant facilities.

Product Brief

P0916DC belongs to Foxboro I/A Series legacy DCS FBM2XX termination‑cable spare‑part family,obsolete original pre‑terminated signal‑cable assembly matched for FBM204 module. Must be used with corresponding FBM termination assembly. Widely used for original Foxboro DCS equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation.
