GA32NA 2/2 Way Solenoid Valve

Feature & Principle

It is a direct-acting or pilot-operated two-position two-way solenoid valve. When the coil is energized, the magnetic force lifts the plunger to open the valve port; after power off, spring force pushes the plunger to close the passage. Normally closed type by default. Brass valve body with NBR / EPDM seal, good corrosion resistance, fast response, used for automatic cut-off of liquid and gas pipelines.

Specifications

Model: GA32NA Type: 2/2 way, Normally Closed Valve body material: Brass Seal: NBR / EPDM Connection: Thread Medium: Water, compressed air, light oil Working pressure: 0~1.0MPa Coil voltage: AC220V / DC24V optional Application: Water treatment, HVAC, irrigation, general pneumatic system Certification: CE

Components & Diagnostics

Brass valve body, electromagnetic coil, movable iron plunger, return spring, sealing diaphragm, terminal wiring base. Common faults: coil burnout, seal aging leakage, plunger stuck, valve cannot open or close.

Product Brief

GA32NA solenoid valve, industrial fluid control spare widely used for water treatment, air conditioning and automatic pipeline maintenance and replacement.
