GE CK09BE311N Magnetic Contactor

Feature & Principle

After the coil is energized, electromagnetic force pulls the moving contact to close and switch on the main power circuit to start the motor. When power supply is lost, the return spring separates the contacts to cut off the circuit. Auxiliary contacts provide status feedback signal for PLC interlock control, and arc extinguishing structure suppresses electric arc during contact breaking.

Specifications

Model: CK09BE311N Brand: GE Industrial Solutions (ABB) Pole: 3P AC3 rated current: 192A Coil voltage: 220~250V AC/DC Auxiliary contact: 1NO + 1NC Rated working voltage: 690V AC Mounting: Screw fixed Certification: UL, CSA, IEC, CE

Components & Diagnostics

Electromagnetic coil, main contact assembly, arc extinguishing chamber, return spring, auxiliary contact block. Common faults: coil burnout, contact ablation and welding, no pull-in after energization, auxiliary contact signal failure, serious heating.

Product Brief

CK09BE311N magnetic contactor, GE heavy-duty electrical spare widely used for water pump, fan and large motor control cabinet transformation and maintenance.
