GE Fanuc IC3600SPSV1D Turbine Control PCB Board

Technical SpecificationsModel：IC3600SPSV1D Brand：GE Fanuc Product Type: Single-slot plug-in printed circuit board for Speedtronic Mark I / Mark II gas turbine control rack

Module Feature:Function: Provide precision regulated DC power supply for other rack boards; perform analog signal conditioning, filtering and reference voltage generation for turbine monitoring and protection circuits. Onboard linear power regulation circuit Precision reference voltage source for analog measurement Multi-channel signal filter and buffer circuit Gold edge connector for backplane interconnection PCB integrated resistors, capacitors, diodes and operational amplifiers Built-in test points for field voltage and signal measurement Single slot rack form factor, rugged industrial PCB laminate Designed to withstand power plant high EMI environment No built-in LED indicators, status verified via external test points

Electrical Parameters:Input Power: Rack raw DC supply Output: Regulated ±15VDC, +5VDC for other Speedtronic cards Low noise output for high-precision analog circuits

Mechanical & Structure:Mounting:Plug-in installation into Speedtronic Mark I / Mark II rack slot Protection class:IP20 Weight:0.62kg

Environmental:Operating temperature:0℃ ~ +65℃ Ambient humidity:5~95% non-condensing Certification:UL, CE approved Status:Manufacturer discontinued legacy spare part

System compatibility

IC3600SPSV1D belongs to GE Fanuc Speedtronic Mark I / Mark II turbine control series. Compatible with Speedtronic control rack and other analog/protection PCB cards. Widely applied on gas and steam turbine power generation safety and monitoring system.

Function

IC3600SPSV1D is power regulation and signal conditioning circuit board manufactured by GE Fanuc for legacy Speedtronic turbine control cabinet. It converts raw rack power into stable, low-noise ±15V and +5V power for adjacent signal and protection cards. It also generates precision reference voltage and filters noisy analog sensor signals. Test points on PCB allow maintenance personnel to measure output voltage and signal quality during troubleshooting.

Installation

Follow lockout/tagout safety procedure before installation. Fully cut off turbine control rack power. Insert IC3600SPSV1D into vacant rack slot and secure retainer. Inspect gold edge pins for oxidation or damage. Restore power, use multimeter at onboard test points to verify regulated voltage and signal quality.

Interface

Speedtronic rack gold-edge backplane connector, onboard test point terminals, power and analog signal traces for GE Fanuc IC3600SPSV1D.

Feature

Original GE Fanuc IC3600SPSV1D Speedtronic power & signal conditioning PCB,precision linear power regulation,low-noise reference voltage,analog signal filtering,accessible onboard test points,high anti-EMI industrial PCB design,UL & CE certified. This spare unit is used for power plant legacy Speedtronic turbine control cabinet maintenance and hardware replacement.

Diagnostic

No regulated voltage output:Check rack raw power and backplane pin contact. Voltage drift / unstable reference:Inspect aging electrolytic capacitors. Excessive signal noise:Check grounding path and shield wiring of field sensors.

Product Brief

IC3600SPSV1D is GE Fanuc legacy Speedtronic Mark I/II power and signal conditioning PCB board,supplies stable regulated power and reference signals for gas turbine control rack,discontinued turbine spare circuit card
