GE Fanuc IC695CPE400 CPU Controller

Technical SpecificationsModel：IC695CPE400 Brand：GE Fanuc Product Type: Rackless standalone PACSystems RX3i CPU controller

Module Feature:Function: Standalone rackless CPU controller for PACSystems RX3i platform, executes real-time deterministic control logic and edge computing via integrated Field Agent. Processor:1.2GHz quad-core processor with real-time hypervisor Memory:64MB program & data RAM,64MB non-volatile flash memory I/O reference table:32k discrete input/output bits,32k analog input/output words Programming languages:Ladder Diagram, Structured Text, Function Block Diagram, C language Communication ports:Four independent 10/100/1000Mbps Ethernet ports Supported protocols:EGD, Modbus TCP, OPC UA, Predix cloud connection LED indicators:OK, RUN, FAULT, Ethernet link status lights Hardware self-diagnosis:memory integrity, firmware verification, network health and internal circuit monitoring Programming software:Proficy Machine Edition

Electrical ParametersPower supply:18~30VDC, max 20W

Mechanical & Structure:Mounting: Cabinet panel mount Dimension:203.5mm ×56.7mm ×153.6mm Weight:0.85kg Protection class:IP20

Environmental:Operating temperature:-40℃ ~ +70℃ Ambient humidity:5~95% non-condensing Certification:UL, CE Status:Manufacturer discontinued legacy spare part

System compatibilityIC695CPE400 belongs to GE Fanuc PACSystems RX3i family. Compatible with RX3i expansion I/O modules and remote backplanes. Widely applied in factory automation, packaging machinery and edge data acquisition systems.

FunctionIC695CPE400 is rackless RX3i CPU controller. Real-time hypervisor runs PLC control logic and Field Agent edge application simultaneously without mutual interference. Multiple Gigabit Ethernet ports support peer communication, HMI connection and secure cloud data upload. Flash memory stores firmware and user program. Onboard LEDs display running state and fault information for field maintenance.

InstallationFollow lockout/tagout safety procedure before installation. Mount IC695CPE400 on cabinet panel. Connect 24VDC power supply and Ethernet cables. Configure network parameters, control logic and edge agent settings in Proficy Machine Edition. Power on and verify program execution and network communication.

InterfacePower terminal block,four RJ45 Gigabit Ethernet ports,on-board RUN / FAULT / LINK LED indicators for GE Fanuc IC695CPE400.

DiagnosticCPU cannot enter RUN mode:Check 24VDC power,valid downloaded project and memory backup condition. Network communication abnormal:Inspect Ethernet cable,IP address configuration and switch port status. Fault LED active:Firmware corruption,memory error or internal hardware failure.

Product BriefIC695CPE400 is GE Fanuc legacy PACSystems RX3i rackless CPU controller with Field Agent edge computing,used for real-time PLC control and industrial cloud data transmission,discontinued automation spare.
