GE Fanuc IC695CRU320-EN CPU Processor Module

Technical SpecificationsModel：IC695CRU320-EN Brand：GE Fanuc Product Type: Single-slot plug-in high-performance CPU processor module for PACSystems RX3i universal backplane

Module Feature:Function: High-end main controller for PACSystems RX3i PLC rack, executes user control logic, handles large I/O scanning and serial communication, supports ECC memory protection. Processor speed:1GHz processor User memory:64MB battery-backed RAM + 64MB non-volatile flash memory Max discrete I/O:32K bits Max analog I/O:32K words Onboard ports:1×RS232,1×RS485 serial port Supported protocols:Modbus RTU Master/Slave, SNP, Serial I/O Boolean execution speed:0.047ms per 1000 boolean instructions Memory:ECC error correction memory, single-bit correction, multi-bit detection LED indicators:OK, RUN, FAULT, FORCE, I/O ENABLED diagnostic lights Hardware self-diagnosis:ECC memory monitoring, logic execution check, backplane bus detection, serial port self-test Programming software:Proficy Machine Edition EN = hardware revision variant

Electrical ParametersBackplane supply:+3.3V max 1.0A; +5V max 1.2A Power consumption:Max 7.8W Battery for memory data retention, sold separately

Mechanical & Structure:Mounting:Plug into RX3i universal backplane single slot Weight:0.30kg Protection class:IP20

Environmental:Operating temperature:0℃ ~ +60℃ Ambient humidity:5~95% non-condensing Certification:UL, CE Status:Manufacturer discontinued legacy spare part

System compatibilityIC695CRU320-EN belongs to GE Fanuc PACSystems RX3i platform. Compatible with RX3i backplane, power supply and all IC695 series I/O and communication modules. Widely used in power, petrochemical and complex process control applications requiring high reliability and large memory capacity.

FunctionIC695CRU320-EN is high-performance PACSystems RX3i CPU module. It is equipped with 1GHz processor and large 64MB RAM/Flash storage, supports ECC memory error correction to improve system stability. Built-in RS232 and RS485 serial ports can connect serial field instruments and drives. It supports large quantity of discrete and analog I/O points for complex automation control projects.

InstallationFollow lockout/tagout safety procedure before installation. Cut off rack backplane power. Insert IC695CRU320-EN into RX3i backplane slot and lock retainer. Install backup battery for memory retention. Connect RS232/RS485 serial cables as required. Download hardware configuration and user program in Proficy Machine Edition. Power rack on and switch CPU to RUN mode.

InterfaceRX3i backplane gold-edge connector,RS232 port,RS485 port,on-board OK / RUN / FAULT / FORCE / I/O ENABLED LED indicators for GE Fanuc IC695CRU320-EN.

DiagnosticCPU cannot enter RUN mode:Program error, hardware configuration mismatch or I/O module fault. FAULT LED lit:ECC memory error, backplane bus failure or hardware defect. Serial communication failure:Baud rate mismatch, wrong protocol or cable wiring fault.

Product BriefIC695CRU320-EN is GE Fanuc legacy PACSystems RX3i high performance 1GHz CPU module,with ECC memory and dual serial ports for complex industrial process control,discontinued industrial CPU spare card.
