GE IS200STAIH2ACB Mark VIe Analog Input Terminal Board Unit

Feature & Principle

This terminal board receives 4-20mA and ±10V analog signals from pressure, temperature and vibration transmitters. It completes signal filtering and protection, transmits conditioned signals to the Mark VIe I/O processor for turbine closed-loop control and safety interlock. On-board ID chip supports automatic hardware identification and mismatch fault diagnosis.

Specifications

Model: IS200STAIH2ACB Brand: GE Series: Speedtronic Mark VIe Signal type: 4-20mA, ±10VDC analog input Mounting: DIN rail / rack installation Application: Gas turbine, steam turbine control cabinet Certification: CE

Components & Diagnostics

Signal conditioning circuit, terminal block, identification chip, status LED, backplane connector. Common faults: channel signal loss, hardware ID mismatch alarm, signal drift, terminal burnout.

Product Brief

IS200STAIH2ACB analog terminal board, GE turbine control spare widely used for power plant gas and steam turbine Mark VIe system overhaul.
