GEN-85-P-D-ST Pressure Regulator

Feature & Principle

It is a direct operated pressure regulator. It balances spring force and medium pressure automatically to stabilize outlet pressure. The internal diaphragm senses downstream pressure and adjusts the opening of the valve spool continuously. It maintains stable outlet pressure even with fluctuation of inlet pressure or flow rate. Compact structure, easy on-site pressure setting, widely used for process gas, compressed air and liquid loop pressure control.

Specifications

Model: GEN-85-P-D-ST Type: Direct acting pressure regulator Wetted material: Stainless steel Pressure adjustment: Adjustable range Port option: Gauge tapping port Media: Compressed air, inert gas, clean liquid Mounting: Pipeline installation Ingress protection: IP65 Application: Chemical pipeline, gas supply system, test bench, process control loop Certification: CE

Components & Diagnostics

Adjustment spring, sensing diaphragm, valve spool, valve seat, body, adjustment knob. Common faults: pressure cannot be stabilized, seat leakage, diaphragm damage, adjustment failure.

Product Brief

GEN-85-P-D-ST direct acting pressure regulator, industrial pipeline pressure control spare widely used for process system overhaul and replacement.
