HEIDENHAIN LHC-05C-S Incremental Linear Encoder Read Head

Technical Specifications

Model：LHC-05C-S Brand：HEIDENHAIN Product Type: Exposed incremental optical linear encoder scanning head

Module Feature

Function: LHC-05C-S is an exposed incremental linear scanning head. It reads optical grating scale tape and outputs 1Vpp sine/cosine incremental signals for linear position and velocity measurement. High resolution up to 5 nm, designed for ultra-precision machining applications. Widely used on heavy horizontal boring mills, surface grinders and ultra-precision machining centers.

Measuring principle: Incremental optical interferential scanning Output Signal: 1 Vpp sine/cosine incremental signals Resolution: 5 nm Max traversing speed: 240 m/min Onboard components: Optical scanning assembly, signal processing circuit, metal housing, multi-pin connector

LED indicators: POWER, SIG, FAULT diagnostic lights

Hardware self-diagnosis

Signal amplitude monitoring, grating contamination detection, signal integrity inspection

Programming software

HEIDENHAIN diagnostic software for signal quality check and mounting adjustment

Electrical Parameters

Supply voltage: 5VDC ±10% Power consumption: Max 2.5W

Mechanical & Structure

Mounting: Scanning head mounted on moving slide carriage; grating scale fixed to machine bed Protection class: IP64 (read head)

Environmental

Operating temperature: 0℃ ~ +70℃ Ambient humidity: 5~85% non-condensing Certification: CE Status: High-precision exposed linear encoder scanning head

System compatibility

Compatibility description: LHC-05C-S works with matched incremental scale tape and HEIDENHAIN EXE interpolation units. Suitable for Fives Giddings & Lewis PIC900 CNC heavy boring mill precision feed axis.

Function

Function description: LHC-05C-S optical scanning head captures linear displacement by reading phase grating. It converts mechanical movement into analog sine/cosine signals for position interpolation. Reference mark signal is required for axis homing after power-up. Compact housing adapts to tight installation space. It is high precision linear measuring spare for heavy CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Cut off encoder 5VDC power. Mount grating scale parallel to travel axis. Install LHC-05C-S scanning head on slide carriage, adjust air gap and parallelism. Connect shielded encoder cable to interpolation unit. Restore power, verify LED indicators, run signal test and axis homing calibration.

Interface

Interface list: Multi-pin flange connector, 5VDC power and 1Vpp signal terminals,on-board POWER / SIG / FAULT LED indicators for HEIDENHAIN LHC-05C-S.

Diagnostic

Troubleshooting: No position reading: Check 5V supply, cable breakage or connector pin damage. FAULT LED lit: Low signal amplitude, grating contamination or read head misalignment. Intermittent position jump: Vibration, improper scanning gap or debris on grating.

Product Brief

Brief description: LHC-05C-S is HEIDENHAIN high-precision exposed incremental linear scanning head with 5nm resolution and 1Vpp output,for ultra-precision feed axis measurement on heavy CNC boring mills,linear read head spare.
