ICS TRIPLEX T8300 Expander Chassis

Technical Specifications

Model:T8300

Brand:ICS TRIPLEX

Product type:TMR expander chassis

System series:Trusted T8000 SIS

Bus type:Triple redundant parallel backplane bus

Compatible modules:T8310 expander processor,T8311 expander interface,T84xx I/O modules,power supply and blank filler panels

Redundancy:TMR triple modular redundant hot swap architecture

Power bus:24VDC power supply from rack power module

Operating temperature:0~+60℃

Relative humidity:5~95% non-condensing

Weight:4.80kg

Certification:CE,TÜV,SIL3

System compatibility

This expander chassis hardware belongs to ICS TRIPLEX Trusted SIS safety instrumented system. It works together with T8100 main controller chassis as I/O expansion rack. It holds expander processor and various T84xx I/O modules,extends system I/O capacity for large-scale safety applications. Widely deployed in oil & gas,petrochemical and chemical plants for ESD emergency shutdown and fire & gas safety protection.

Function

T8300 serves as the high integrity mechanical and electrical expansion rack unit of Trusted TMR SIS. It provides multiple installation slots and triple redundant backplane bus for expander processor and I/O modules. It continuously monitors backplane bus integrity and slot contact status. It expands the main controller’s I/O capacity while retaining full TMR fault tolerant safety features.

Installation

Mount T8300 expander chassis to standard 19-inch cabinet. Insert expander processor and I/O modules vertically into dedicated slots,complete power wiring and expander bus connection,verify communication status and fault diagnosis via Trusted Workbench engineering software.

Interface

‑Triple redundant backplane PCB connector for inter-module communication

‑24VDC power terminal block for rack power input

‑Multiple dedicated slots for expander processor, I/O and blank modules

‑LED indicators for rack power, bus running, alarm and fault prompt

Circuit feature

Conformal coated backplane PCB design,built-in surge and overvoltage protection circuit. Triple channel hardware bus voting design,fully compliant with SIL3 functional safety hardware specifications.

Feature

T8300 is a spare expander chassis for ICS TRIPLEX Trusted SIS system. Common faults include backplane circuit damage,slot contact failure and power distribution abnormality. Confirm expander module and bus compatibility before replacement.

Diagnostic

When backplane disconnection,slot contact failure or hardware breakdown is detected,the chassis will trigger fault alarm and upload diagnostic messages to safety workstation.

Built‑in function

Expansion module mechanical mounting and triple redundant backplane bus communication for Trusted TMR safety expansion rack,used as SIS expander chassis spare replacement.

Product Brief

T8300 is ICS TRIPLEX Trusted SIL3 TMR expander chassis,supporting hot swap T84xx I/O modules and T8310 expander processor. Verify module compatibility before ordering. ESD anti-static protection must be followed during handling installation.
