ILOCZ245113JC Solenoid Valve

Feature & Principle

It works by electromagnetic pilot control. When the coil is energized, magnetic force drives the pilot spool to change the pressure balance inside the valve cavity, so as to open or close the main passage. It supports remote electric switching, used for automatic cut-off and interlock protection of fluid medium.

Specifications

Model: ILOCZ245113JC Type: Pilot solenoid valve Medium: Gas, water, light oil Seal: NBR Voltage: 24VDC Connection: Thread connection Protection: IP65 Certification: CE

Components & Diagnostics

Electromagnetic coil, pilot spool, main valve core, valve body, sealing gasket, return spring. Common faults: coil burned out, valve stuck, internal leakage, no action after power on, external leakage.

Product Brief

ILOCZ245113JC solenoid valve, fluid control spare widely used for water treatment, HVAC and petrochemical pipeline automatic switching control.
