Kollmorgen SR03200-2G205A Servo Motor Spare Par

Technical Specifications

Model:SR03200-2G205A

Brand:Kollmorgen

Part No:SR03200-2G205A

Product type:Permanent magnet brushless servo motor

Rated power:0.32kW

Rated speed:3000rpm

Continuous torque:1.0Nm

Rated voltage:200V AC

Protection class:IP64

Dimension:142mm80mm90mm

Weight:3.2kg

Feedback interface:Incremental encoder

Mounting:NEMA flange mounting

Operating temperature:0~40℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

System compatibility

SR03200-2G205A belongs to Kollmorgen Silverline servo motor family,matched with Kollmorgen BJRL,SR series rack servo amplifiers,widely used in old CNC equipment,small precision positioning machinery,packaging and printing auxiliary axes.This is discontinued industrial spare part for equipment overhaul and maintenance.

Function

SR03200-2G205A is small frame Silverline brushless servo motor with rare earth permanent magnet rotor.It features low cogging torque and smooth running performance.Incremental encoder provides high resolution position and speed feedback for closed-loop motion control.Suitable for light load,continuous cycle operation,optional holding brake configuration.

Installation

Install SR03200-2G205A via standard NEMA flange mounting.Connect motor power cable and encoder feedback cable.Fasten coupling and mechanical connection,complete shielding and grounding inspection before power-on test.

Interface

‑3 phase motor power connector

‑Incremental encoder feedback connector

‑Optional brake terminal

‑Shield grounding terminal

Feature

SR03200-2G205A is obsolete Kollmorgen spare part.Typical faults:winding insulation degradation,encoder damage,bearing wear,shaft seal failure,connector corrosion.Test winding resistance,insulation resistance and encoder pulse signal before replacement.

Diagnostic

Motor faults will trigger overload,overcurrent or position tracking alarm;motor no rotation,abnormal noise,axis jitter,positioning deviation.

Built‑in function:Convert electrical command into precise mechanical torque,realize high accuracy speed and position closed-loop control,as Kollmorgen Silverline series servo motor spare replacement.

Product Brief

SR03200-2G205A is Kollmorgen Silverline 0.32kW brushless servo motor,200V rated voltage,encoder feedback,matched with BJRL series rack drives for legacy light-duty automation equipment repair.Confirm feedback type and brake option before ordering.ESD protection required during handling and installation.
