Lenze E84AVSCE3734VX0 8400 Drive Unit

Module Feature

E84AVSCE3734VX0 belongs to Lenze 8400 StateLine C vector inverter series.

It supports V/F control and sensorless vector control, provides stable torque output at low speed. It has built-in application function blocks, optional CANopen and PROFIBUS communication modules. This drive is widely used in packaging machinery, conveying lines, fans and pumps in factory automation.

Working principle

Three-phase AC power is rectified into DC bus voltage, and the IGBT power stage outputs adjustable PWM AC.

The microprocessor executes vector algorithm to realize closed-loop current and speed control. It integrates multi-protection logic including overcurrent, overvoltage, phase loss, overload and overtemperature, and outputs fault signals to upper control system.

Onboard components

Rectifier bridge, IGBT power module, DC bus capacitors, current sampling circuit, control mainboard, cooling fan, terminal block and expansion slot.

LED indicators

Front LEDs show power supply, running status, alarm warning and fault code indication.

Hardware self‑diagnosis

Power-on self-test and continuous monitoring detect phase failure, overheating, DC bus out of range and communication error, fault information can be checked by local panel or engineering software.

Programming software

Lenze L-force Engineer, used for motor identification, parameter setting, logic configuration and fault record reading.

Electrical & Process Parameters

Model:E84AVSCE3734VX0 Brand:Lenze Device type:8400 StateLine C vector inverter Voltage:400V 3-phase AC Function:Asynchronous motor speed, torque control and automation communication

Mechanical & Structure

Mounting:Cabinet wall mounting

Protection class:IP20

Housing:Metal modular drive enclosure

Environmental

Operating temperature:0℃ ~ +45℃

Storage temperature:-40℃ ~ +85℃

Ambient humidity:5~95% non‑condensing

Certification:CE, UL

Status:Original Lenze automation drive spare

Installation

Install inverter vertically in ventilated cabinet.

Connect main power, motor cable and control wiring, complete motor identification and protection setting before commissioning.

Interface

3-phase power terminals, motor output terminals, analog/digital I/O, fieldbus expansion slot.

Diagnostic

Overcurrent fault: Motor short circuit, ground fault or incorrect acceleration time.

Overheat alarm: Fan failure, blocked air duct or excessive ambient temperature.

Communication interruption: Wrong bus address or loose communication connector.

Product Brief

Lenze E84AVSCE3734VX0 8400 StateLine C vector inverter, high-performance frequency converter for packaging and conveying equipment maintenance replacement.
